Specifications
Model Number :
UND-AM50
Type :
RF Module
Place of Origin :
China
Brand Name :
UND
Output Power :
50W
Frequency :
720-1020 MHz
Dimension :
117*40*18 mm
Weight :
230g
MOQ :
1
Price :
Please consult a sales engineer
Delivery Time :
5-8 days
Payment Terms :
T/T
Supply Ability :
100
Description
Customized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF Modules

Test items

Index

Unit

Remark

Frequency range

700-1000

Mhz

With signal source

Operating voltage

24-32

V

Typical voltage 28V built-in voltage regulator module

Maximum output power

50

dBm

≤7.3A

Power supply requirements

≥10

A

Work efficiency

50

%

Typical work efficiency

Output port VSWR

≤2

High and low temperatur e test

Working environment temperature
(℃)

-40~+55

℃

Power stability

1.5

dB

-20℃~+75℃

Power supply

M4 Feedthrough
Capacitor

Red and black wire or
through-hole capacitor

Communication interface

CON2*4

1,2,3,4 pin NC
8pin enable (hight open, low close)
6pin temperature alarm (normal high level, alarm low level) 7pin standing wave alarm (normal high
level, alarm low level)
5pinGND

RFoutput connector

N

Female

Size

156.5*64.7*24.5

mm

Not including connector

Mounting holes

151.5*59.4

M3*10 steel screw
Customized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF Modules

ABOUT US
Customized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF Modules

Certification

Customized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF ModulesCustomized 700mhz 50W GaN Lora RF Module Anti-FPV Unit for Defense System Amplifier Power Wireless & RF Modules

1. How long is the production lead time?
The production lead time varies depending on the product and order quantity. Generally, it takes around 7-15 days after receiving the deposit. Please contact us for more accurate information based on your order.
2. Can I customize the product?
Yes,Power and frequency band can be customized according to your needs
Please contact us with your specific requirements.
3. What is your payment term?
We accept various payment methods, including T/T (Telegraphic Transfer), PayPal, and Alibaba Trade Assurance.
Payment terms are typically 30% deposit and 70% balance before shipment.
4. How do you ensure product quality?
We have a strict quality control process, including raw material inspection, in-production checks, and final quality inspections before shipment.
5. What shipping methods are available?
We offer multiple shipping options, including sea freight, air freight, and express courier (DHL, FedEx, UPS, etc.). We will
recommend the most suitable method based on your order quantity and destination.
6. Can I track my order?
Yes, we will provide you with a tracking number once your order is shipped.
You can use this number to track your order through the carrier's website.
7. Do you provide after-sales service?
Yes, we offer comprehensive after-sales support, including technical assistance and warranty services.
Please contact our customerservice team for any issues related to your order.
