Multifunctional XY-1 Hard Rock Geological Drilling Rig 100m Underground Coring


Description


Geological Drilling Rig Machine is a new-design light-weight, high efficiency mainly applied to drill drilling water Wells, agricultural irrigation Wells and other well, especially for the mountain area and rock stratum for water supply projects. The rig adopt new type hydraulic pressure technology, and match a complete set of hydraulic motor with high torque and large diameter cylinder turn of the hydraulic oil cylinder propulsion.


Technical and parameter


XY-1 Rig Technical Specifications
Main technical parameters
Pump
Drilling depth(m) 100m Type Gear pumps
Hole diameter 110mm Model YBC-12/80
The final hole diameter 75mm Rated pressure 8Mpa




Rod diameter 42-50mm Flow 8ml/r
Borehole inclination 90°— 75° Rated speed 1500r/min




Rig Dimensions 1640mm×1030mm×1440mm

(L×B×H)


Rig weight(Except the power machine 500kg Motor and diesel
Gyrator
type ZSⅡ00
vertical speed 142,285,570r/min Rated Power 11KW
vertical stroke 450mm Rated speed 2200r/min
vertical load up the maximum speed 3m/min Electric motor
vertical load down the maximum speed 4m/min type Y160M-4
The maximum vertical force feed 15KN Rated Power 11KW
The maximum vertical lifting force 25KN Rated speed 1460r/min


Pump
Winches
Type Horizontal single-cylinder double-acting
The maximum lifting capacity ( a single rope speed ) 10KN The maximum displacement 99(77)L/min
Reel speed 55,110,220r/min The maximum allowable pressure 1.2Mpa
Roll peripheral speed 0.42,0..84,1.68m/s Working Pressure 0.7Mpa
Reel diameter 145mm The number of strokes 120(96)min
Rope diameter 9.3mm Liner diameter 80mm
Rope capacity 27m Piston stroke 100mm
Brake diameter 230mm

Gate width 50mm


Application Scope


‑ Geological survey & core sampling
‑ Engineering geotechnical investigation for road, bridge, building and dam
‑ Blasting hole, grouting hole, test borehole drilling
‑ Small‑scale domestic water well drilling
‑ Geophysical exploration project

Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：

Pneumatic Drilling Rig / Air Drilling Rig（ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter

OEM / ODM can accept. Good quality, professional after-sales service, welcome to order
