Interlocking 120m Kelly Bar Drilling For Engineering
Interlocking 120m Kelly Bar Drilling For Engineering
Specifications
Brand Name :
JTHL
Model Number :
sr40 sr60 sr70 sr80 bg24 bg28 bg36
Certification :
ISO9001
Place of Origin :
CN
MOQ :
1
Price :
USD 10000-USD 50000/set
Payment Terms :
Western Union, L/C, D/P, T/T
Supply Ability :
100 + sets + 1 year
Delivery Time :
7-10 working days
Packaging Details :
steel guide
Warranty :
6 months
Material :
Q345B,35CrMo,27SiMn,16Mn for drilling bit; 16Mn/35CrMo for kelly bar; Q235 for tremie pipe
After-sales service provided :
Video technical support,Online support,Engineers available to service machinery overseas,Field maintenance and repair service,Field installation
Type :
Customerized,interlocking or friction kelly bar,Kelly Bar
Name :
Kelly Bar,Rotary Drilling Rig Kelly Bar
Drilling depth :
20-120m
Use :
deep foudation
Tube material :
Alloy seamless steel tube
Machine type :
for foundation construction rotary drilling rig
Advantage :
Six-key design and parts with imported material
Description

Interlocking Kelly Bar Drilling For Engineering

Interlocking Kelly Bar:

No.

OD

Section

Way of crowding

Length of per section(m)

Drill depth

 Torque
1 ¢299 3 4

(interlock-type)

 9-12 24-45 100 -120
2 ¢342 3 4

(interlock-type)

 9 - 12 24-45 100 -120
3 ¢355 3 4 (interlock-type) 9 - 14 24 - 56 100-120
4 ¢368 3 4

(interlock-type)

 9 - 14 24 - 56 150-180
5 ¢377 3 4

(interlock-type)

 9 - 14 24 - 56 150-180
6 ¢394 3 4

(interlock-type)

 9 - 15 24 - 58 180-200
7 ¢406 3 4

(interlock-type)

 9 - 15 24 - 58 180-200
8 ¢419 3 4

(interlock-type)

 9 - 15 24 - 58 200-230
9 ¢440(445) 3 4

(interlock-type)

 9 - 15 24 – 58 220-260
10

¢470

(482)

 3 4

(interlock-type)

 9 - 16 24 – 60 220-260
11 ¢508 3 4

(interlock-type)

 9 – 18 24 – 68 260-360
12

¢530

(540)

 3 4 5

(interlock-type)

 9 – 20 32 – 92 320-400
13 ¢580(575) 3 4 5

(interlock-type)

 9 – 20 32 – 92 360-420
14 ¢630 3 4 5

(interlock-type)

 9 - 22 32 - 102 400-500

dvantage & Features
a). high quality material and rich manufacturing experience in welding process.
b). reasonable price and advanced processing facilities.
c). professional experienced engineers group from R&D department.
