120m Interlocking Kelly Bar For Rotary Drilling Rig
120m Interlocking Kelly Bar For Rotary Drilling Rig
Specifications
Brand Name :
sany
Model Number :
sr155 sr220 sr235 sr405 sr285
Certification :
ISO9001
Place of Origin :
beijing
MOQ :
1
Price :
$10000-$50000/set
Payment Terms :
Western Union, L/C, D/P, T/T
Supply Ability :
100 + sets + 1 year
Delivery Time :
7-10 working days
Packaging Details :
steel guide
Name :
Kelly Bar,Rotary Drilling Rig Kelly Bar
Color :
Customized
Warranty :
6 months
Material :
Q345B,35CrMo,27SiMn,16Mn
After-sales service provided :
Video technical support,Online support,Engineers available to service machinery overseas,Field maintenance and repair service,Field installation
Drilling depth :
20-120m
Processing type :
Hot treatment and forging
Use :
deep foudation
Usage :
rotary drilling rig
Tube material :
Alloy seamless steel tube
Description

Interlock Kelly bar adopts the international advanced six-ribs distribution technology. The inner keyboards and outer keyboards are manufactured from overall forging and pressing high-tensile steel . The special heat treatment which make this style Kelly bar with high abrasion resistance, compression resistance and excellent welding properity.

120m Interlocking Kelly Bar For Rotary Drilling Rig

.
120m Interlocking Kelly Bar For Rotary Drilling Rig120m Interlocking Kelly Bar For Rotary Drilling Rig120m Interlocking Kelly Bar For Rotary Drilling Rig120m Interlocking Kelly Bar For Rotary Drilling Rig

No.

OD

Section

Way of crowding

Length of per section(m)

Drill depth

Torque

1¢29934

(interlock-type)

9-1224-45100 -120
2¢34234

(interlock-type)

9 - 1224-45100 -120
3¢35534

(interlock-type)

9 - 1424 - 56100-120
4¢36834

(interlock-type)

9 - 1424 - 56150-180
5¢37734

(interlock-type)

9 - 1424 - 56150-180
6¢39434

(interlock-type)

9 - 1524 - 58180-200
7¢40634

(interlock-type)

9 - 1524 - 58180-200
8¢41934

(interlock-type)

9 - 1524 - 58200-230
9¢440(445)34

(interlock-type)

9 - 1524 – 58220-260
10

¢470

(482)

34

(interlock-type)

9 - 1624 – 60220-260
11¢50834

(interlock-type)

9 – 1824 – 68260-360
12

¢530

(540)

345

(interlock-type)

9 – 2032 – 92320-400
13¢580(575)345

(interlock-type)

9 – 2032 – 92360-420
14¢630345

(interlock-type)

9 - 2232 - 102400-500
