5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
Specifications
Brand Name :
HLDRILL
Place of Origin :
CHINA
MOQ :
10PCS
Price :
Please contact us
Payment Terms :
T/T
Supply Ability :
3000 PCS Per month
Delivery Time :
7-15 Days
Certification :
ISO 9001 Certified
Packaging Details :
Wooden Boxes, Cardboard Boxes
Face :
flat、drop center 、New drop center
Material :
Tungsten Carbide
Threadtype :
R、T、S、SR、ST
Weight :
1 kg
Wearresistance :
High
Diameter :
59mm
Usageenvironment :
Mining, Construction, Quarrying
Compatibility :
Compatible with most drilling rigs
Application :
Drilling
Name :
Button Bit
Description
5-tooth 59mm diameter R32 threaded button bit for efficient rock drilling in mining and tunneling
Product Specifications
Product Name 5-tooth diameter 59mm R32 threaded button bit
Diameter 59mm
Thread Type R32
Length 95mm
Carbide Dimension 2×12mm, 3×15mm
Weight 1 kg
Water Holes 1 on front, 1 on side
Skirt Design Standard
Steel Grade 42CrMo, 45CrNiMoVA
Product Overview
The Henglong 5-tooth, 59mm diameter R32 threaded ball tooth drill bit is a down-the-hole hammer drill bit engineered for demanding applications in mining, tunneling, and construction. Featuring R32 standard wave thread for reliable torque transmission, this drill bit delivers exceptional performance in medium-sized drilling operations.
Key Features & Benefits
  • Five spherical carbide teeth optimize impact force and penetration power for efficient rock breaking
  • Higher pressure distribution on hard rocks due to fewer teeth configuration
  • Heat-treated alloy steel shank provides superior fatigue resistance
  • Low-temperature carbide brazing creates strong connections, reducing button loss risk in high-stress applications
  • Reduced replacement costs through optimized tooth configuration
5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling5 Tooth 59mm R32 Threaded Button Bit For Mining / Tunneling Rock Drilling
Primary Applications
Mining development, tunnel excavation, slope support, foundation engineering, water well drilling, bolt holes, blasting holes, and small-scale exploration operations.
