Steel Body Six-Blade PDC Drill Bits 17 1/2″ 444mm XD6163D for Oil Gas Well Directional Drilling
Steel Body Six-Blade PDC Drill Bits 17 1/2″ 444mm XD6163D for Oil Gas Well Directional Drilling
Steel Body Six-Blade PDC Drill Bits 17 1/2″ 444mm XD6163D for Oil Gas Well Directional Drilling
Steel Body Six-Blade PDC Drill Bits 17 1/2″ 444mm XD6163D for Oil Gas Well Directional Drilling
Specifications
Nozzle type&count :
L*9
Gauge Length :
79mm
Junk slot area (sq mm) :
51586
Make-Up TQ :
Make-Up TQ
Price :
Negotiable
Brand Name :
XINGTONG
IADC code :
S123
Certification :
API 、ISO 9001
Payment Terms :
L/C,D/P,T/T,
Supply Ability :
Stable supply and support for bulk customization.
Delivery Time :
15-45 Days
Packaging Details :
Standard Exported Package
Approximate Shipping Weight :
455kg
Model Number :
17 1/2″ 444mm XD 6163D
API Connection :
7-5/8 REG.pin
Face :
60
Normalized Face Volume :
77.0%
Gauge :
11
Make-Up Length :
605mm
MOQ :
1 Piece（MOQ）
body type :
STEEL body
Total Cutter Count :
71
Place of Origin :
CHINA
Cutter Type :
GII
Description
PDC Drill Bits Steel Body Six-Blade 17 1/2″ 444mm XD6163D for Oil Gas Well Drilling Tools
XD Series Features
  • Suitable for improving the steerability and overall drilling efficiency for both RSS and bent motor
  • Shank-less design reduces make-up length by 40% compared to conventional bits, significantly improving steerability
  • Unique depth of cut control design provides excellent tool face control, even with higher than normal WOB conditions
  • Drilling with bent motor: maximum DLS ≥30°/30m. Drilling with RSS: maximum DLS ≥15°/30m
Product Features
  • Full Gauge
  • Hard facing
Important Notes
  • The recommended top-buckle torque is set according to the inner and outer diameter of the joint, with reference to API7G
  • The technical performance of the drill bits sold by Xingtong will be fully implemented in accordance with the terms agreed between Xingtong and the customer
  • The pictures are for reference only. Please contact Skycom engineers for detailed technical parameters
