High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-FP87
Certification :
ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
Place of Origin :
China
MOQ :
1
Price :
USD780 to USD4500 Per Piece
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1590 Pieces Per Month
Delivery Time :
5-6 Work Days
Packaging Details :
Wooden Pallet, Wooden Case
Productname :
Floating Pipeline
Applications :
mud,dredge,water suction and discharge etc
Feature :
Wear Resistance
Color :
Customized Color
Length :
Customized Length
Working temperature :
-40℃ (-40℉)to 100℃(212℉)
Size :
2inch~16inch
Pressure :
10-21Bar
Description
Floating Pipeline - Heavy Duty Offshore Conveying System
The Floating Pipeline is a heavy-duty offshore conveying system designed for high-capacity dredging, industrial slurry transport, and marine engineering projects. It features a reinforced multi-layer structure with high-abrasion resistant inner rubber lining that ensures durability under continuous hydraulic pressure and abrasive material flow.
The system incorporates precision-engineered buoyancy design that enables stable floating performance across offshore routes without requiring external support systems. It is capable of transporting sand, sediment, and slurry mixtures over long distances with high efficiency and low energy loss. Its corrosion-resistant and weather-resistant construction ensures reliable performance in harsh marine environments including high salinity seawater, strong UV exposure, and variable temperature conditions.
Case Study: Saudi Arabia Coastal Development Project
In a coastal development project in Saudi Arabia, engineers were tasked with reclaiming over 3 million cubic meters of sand for new industrial land expansion. The project faced extreme environmental challenges including high temperatures exceeding 45°C, strong coastal winds, and long offshore pumping distances.
Traditional pipeline systems experienced instability and frequent maintenance interruptions. After adopting Hongruntong Marine Floating Pipeline, the system maintained consistent buoyancy and stable discharge performance throughout continuous operation. The reinforced structure effectively resisted deformation caused by wave impact and thermal expansion. The project achieved a 31% improvement in dredging speed and significantly reduced operational downtime, allowing completion ahead of schedule.
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
Specifications
Material PTFE, Galvanized Steel Wire, PVC Coated Polyester Cloth
Product Name Floating Pipeline
Inner Wire Stainless Steel 316
Lining Polyamide
Carcass Polyamide fabrics, Polyester films
Outer Wire Stainless Steel 316
Working Pressure 10 bar to 21 bar
Maximum Length 40 meters
Sample Available
Delivery time Normally 3-5 days
Technical Specifications
Model Dimensions [mm] Dimensions [inch] Working Pressure [bar] Working Pressure [psi] Safety Factor Bending Radius [mm] Weight [kg] Length [m]
HM-FDH20 20 3/4" 16 230 6:1 80 0.8 40
HM-FDH25 25 1" 16 230 6:1 100 1 40
HM-FDH32 32 11/4" 16 230 6:1 125 1.3 40
HM-FDH40 40 11/2" 16 230 6:1 140 1.5 40
HM-FDH50 50 2" 16 230 6:1 180 2.5 40
HM-FDH65 65 21/2" 16 230 6:1 200 3.3 40
HM-FDH80 80 3" 16 230 6:1 260 4 40
HM-FDH100 100 4" 16 230 6:1 380 6.8 40
HM-FDH125 125 5" 16 230 6:1 440 9.2 40
HM-FDH150 150 6" 16 230 6:1 500 13.2 40
HM-FDH200 200 8" 16 230 6:1 750 18 40
HM-FDH250 250 10" 16 230 6:1 900 26 25
Note: Various sizes can be customized according to the requirements.
Key Features
  • Heavy Duty Load Bearing Reinforced Structure: Engineered with high-strength multi-layer reinforcement system capable of withstanding extreme tensile loads and internal pressure variations, ensuring structural stability during long-distance offshore transport operations.
  • High Temperature and UV Resistant Material System: Outer layer formulated to resist degradation caused by prolonged sunlight exposure and high ambient temperatures, ensuring long-term performance in desert coastal environments.
  • High Flow Efficiency Internal Channel Design: Inner surface optimized to reduce friction loss and improve slurry flow velocity, resulting in lower energy consumption and higher pumping efficiency.
  • Long Term Stable Buoyancy System: Integrated flotation structure ensures consistent buoyancy distribution even under continuous operational stress and environmental fluctuations.
Applications
  • Desert Coastal Reclamation Projects - Large-scale land expansion and industrial coastal development in high-temperature regions
  • Harbor and Channel Maintenance Dredging - Continuous sediment removal for navigation safety and port efficiency
  • Industrial Slurry Discharge Systems - Mining and industrial waste transport requiring high-volume slurry handling
Why Choose Hongruntong Marine
  • Advanced Material Engineering Expertise: High-performance rubber compounds and reinforced synthetic materials designed specifically for offshore dredging applications
  • Project Specific Engineering Customization: All systems tailored based on hydraulic calculations, environmental conditions, and operational requirements
  • High Reliability Quality Assurance System: Every pipeline undergoes rigorous inspection and testing to ensure consistent performance in real marine conditions
  • Strong International Project Execution Capability: Successfully deployed in large-scale infrastructure projects across multiple continents
Frequently Asked Questions
Can it operate in extreme heat environments?
Yes, it is designed for high temperature coastal and desert marine conditions.
What makes it suitable for long distance transport?
Its low friction design and high pressure resistance enable efficient long distance slurry conveyance.
Is buoyancy affected over time?
No, the integrated system is designed for long term stable flotation performance.
Can it be used for industrial waste transport?
Yes, it is suitable for industrial slurry and waste discharge systems.
Is installation complex for large projects?
No, modular structure allows efficient assembly even in large scale offshore deployments.
High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging High Pressure Floating Dredge Pipeline Slurry Hose For Offshore Dredging
