PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Description

PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC

Quick Detail:

1. EPISTAR LED chip;

2. MBI5224 driving IC;

3. More than 8,000 nits;

4. 960×960 mm cabinet size;

5. 120 degrees viewing angle;

6. About 48 kg/sq.m.

Detail Description:

This type of P10 LED chip is EPISTAR brand, with MBI5224 drive IC, more than 8,000 nits, totally visible under strong sunshine;

The viewing angle could reach to 120°;

It is by synchronization control with IPC or control PC, optical fiber needs to be used for long distance control.

Application:

Such outdoor LED billboard is installed on highway or eye-catching place to play ads, catching people's attention.

Specifications:

Type

PH 10

LED Composition

1R1G1B

LED Type

DIP346

LED Chip

EPISTAR

Module Pixel

W 16 × H 16

Module Size

W 160 × H 160 mm

Cabinet Size

W 960 × H 960 mm

Cabinet Color

Black

Cabinet Material

Steel waterproof cabinet with back door

Drive Method

1/4 scan constant current

Brightness

≥8000 CD/sq.m

Refresh Rate

≥800Hz

Resolution

10,000 dots/sq.m

Drive IC

MBI5224

MTBF

＞5,000 hours

LED Life Span

＞100,000 hours

Power Supply

110V/60HZ and 220V/50HZ interchangeable

Brand

Meanwell

Control Method

Synchronous control with PC on

Operation System

Win2000 / XP / Vista

PH 10 Steel Outdoor LED Billboard Waterproof Cabinet EPISTAR LED MBI5224 IC
