New 2600T Series ABB Pressure Differential Pressure Transmitter 266DSH Wireless HART Communication Protocol
New 2600T Series ABB Pressure Differential Pressure Transmitter 266DSH Wireless HART Communication Protocol
New 2600T Series ABB Pressure Differential Pressure Transmitter 266DSH Wireless HART Communication Protocol
New 2600T Series ABB Pressure Differential Pressure Transmitter 266DSH Wireless HART Communication Protocol
New 2600T Series ABB Pressure Differential Pressure Transmitter 266DSH Wireless HART Communication Protocol
New 2600T Series ABB Pressure Differential Pressure Transmitter 266DSH Wireless HART Communication Protocol
Specifications
Brand Name :
ABB
Model Number :
266DSH
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
100pcs/Months
Delivery Time :
5-8 work days
Packaging Details :
Carton
Pressure Range :
0-10kpa...~2MPa
Stability :
≤ 0 . 2 % URL/ year
Mounting Type :
Direct Mount
Housing Material :
Aluminum
Communication Protocol :
HART
Full Load Power :
2W
Hosing Material :
Aluminum case
Specification :
10kpa~2Mpa
Port Size :
1/4 NPT
Power :
24VDC
Connection Type :
thread
Diaphragm :
Stainless steel
Over Pressure Capacity :
15 times
Description


The 266DSH adopts the wireless HART communication protocol and can add pressure measurement points throughout the entire operation process. Users can monitor hard to reach locations and isolate hazardous environments during operations. The 266 wireless HART pressure transmitter has a battery life of approximately 10 years at a 32 second update rate, providing a very cost-effective and reliable solution for monitoring process control.


1‌. High precision and stability
Range ratio up to 100:1, accuracy up to 0.025%, long-term drift less than 0.15%/10 years, suitable for harsh industrial environments；

Support bidirectional flow measurement and small flow cutoff function, optimize process control；

Electronic modules support on-site replacement and have self configuration capabilities to improve factory efficiency；

2.Performance and Certification

Accuracy up to 0.025%, range ratio 100:1, long-term drift less than 0.15%/10 years;

Certified according to IEC 61508 SIL2/SIL3, suitable for safety critical applications；

3.Communication and Scalability

Supports Wireless HART wireless protocol, with a battery life of up to 10 years (update rate of 32 seconds)；

Can monitor dangerous or difficult to reach measuring points, reducing installation costs；


Product Name Differential Pressure Transmitter
Accuracy ±0.06%
Range 0.05~16000kPa
Output signal 4-20mA+HART
Supply voltage 24(V)
Operation temperature 90(℃)
Protection grade IP68
Measurement medium Measurement medium
Interface size M20*1.5(mm)
