Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds
Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds
Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds
Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds
Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds
Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds
Specifications
Brand Name :
HD , OEM
Model Number :
HD9250G
Certification :
CE
Place of Origin :
Shenzhen ,China
MOQ :
500
Price :
Get the newest price
Payment Terms :
Paypal , T/T, Western Union
Supply Ability :
1500PCS/Per Week
Delivery Time :
20-25days
Packaging Details :
Color Box
Color :
Red + Grey
Usage :
Test instruments
Display type :
Digital Only
Power supply :
9V
Max Dispaly :
1999
Weight :
400g
Description

Professional 600A AC Digital Clamp Meter , Continuty Test , Data Holds

Description

HD9250G is designed and produced in accordance with the safety standards of electronic measuring instruments and hand-held electronic current clamp meter: IEC 1010-1 and IEC1010-2-032. This meter completely conforms to double insulation DC 1000V, AC 750V CAT II and safety standard of pollution degree II.

HD9250G is a kind of 3 1/2 digit clamp meter with wide-range measurement and Multi-function.This meter has a unique and more attractive outline.

This meter applies high-performance A/D transformer and all the components are SMD Surfaced. All the range positions have over-load protection function. AC current is measured through the clamp jaw and it has three positions: 20A, 200A and 1000A. Five other positions can measure AC voltage, DC Voltage, Resistance Diode and Continuity.

This meter has “HOLD” key to make it easier to read and record during the measurement.

This meter has backlight to make it easier for the users to read and record in faint light.

Quik details

Middle Current Clamp meter

DC Current 200/600v

AC Voltage 200v/600v

Resisitance 20KΩ

Jaw Size : 25MM

Max Display 1999

Continuty Test / Auto Power off / Auto Zero Function / Data Holds / Backlight

Specification

DC Voltage

200/600V

AC Voltage

200V/600V

AC Current

20A/200A/600A

Resistance

20KΩ

Continuity Buzzer

√

Auto Zero funciton

√
Backlight √

Data hold

 √

Auto Power off

 √

General Characteristic

Power supply 9V

Jaw size 25mm

LCD size 37*23.5

Meter Size 213*74*32mm

Standard Accessories test lead battery manual

Packing color box

Standard quantity 40pcs


Application

Family ,Laboratory ,Factory ,Field work
