400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles
Specifications
Brand Name :
Dissmann
Model Number :
EV-A-Q
Certification :
UL
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material :
Ceramic
Color :
White
Installation :
Stud Mount
Rated Current :
300A/400A
Rated Voltage :
250VDC
Related Standard :
UL248-20、ISO8820、JASO-D622、RoHS
Applications :
Electric Vehicles、Battery Pack、EV Charging Station
Keyword :
Ceramic Automotive Fuse
Description

China Ceramic Electric Vehicle Fuse For EV Charging Manufacturers

Product descriptions

1.Application of EV fuse

This electric vehicle fuse link is suitable for voltage up to 250Vdc,current up to 400A,breaking capacity of DC20KA.It's design special purpose for EV/HEV automotive,high power EV PDU and battery protection.The fuses dimension and performance conform to IEC60269,UL248-20,ISO8820,JASO-D622,EU and RoHS Detective.

2.Structure of EV fuse element

The melting tube of the EV fuse is made of high -temperature resistance ceramic material, which has high fire performance and solid hardness.
Seal the melt in the melting pipe and make 99.99 % sterling silver into a variable cross -section melt. The melting tube fills the chemical treatment of high -purity quartz sand and specially treated chemical materials as an arc to extinguish the agglomeration.

3.Product dimension in milimeter

400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles

400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles

4.Product system code of EV fuse

400Amps Fast Melting Ceramic Automotive Fuse For Electric Vehicles

5.FAQ

Question 1:Where are the fuses used in?

Answer:Abundant Fuses, product line covers all relevant areas of new energy vehicles (Pack, PDU, BDU, Electric control, Motor, MSD, Low voltage wiring harness), Charging system and the Charging Module, Photovoltaic PV Solar junction box, photovoltaic inverter, UPS power supply, 5G Communication power supply, BS UK plug, Electrical Home Appliances Control Panel, Lighting drive Power Supply and so on
