IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
Specifications
Screen Dimension :
Customized
Drive Mode :
1/20scan,constant current
Color Depth :
RGB
Specification :
Video Wall
Operating Temperature :
-20℃~+60℃
Scan :
1/16
Input Voltage :
AC110-220V
Pixel Config :
1R1G1B 3-in-1
Control System :
Nova/Linsn/Colorlight
Business :
Sales or rental
Protection Level :
IP65
Pitch :
7.62
Maintenance :
Front/rear
Touch Screen Type :
Infrared
Horizontal Viewing Angle :
140º
Place of Origin :
China
Brand Name :
JC
Certification :
CE FCC
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
wooden case，flight case
Delivery Time :
5-7 working days
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
4300 sqm month
Description

Indoor P2.5 LED Display

JC-P2.5 LED Display

P2.5mm indoor fixed LED screen is easy to operate and has powerful content management functions. In addition, various mature overseas projects have improved the overall performance of our P2.5 LED display, and more and more customers choose us as a long-term supplier and supplier of P2.5 indoor LED signs.

Offline Message
Related Case
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
P2.5 Flexible LED Display
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
P2.5 LED Totem Display
IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized
P2.5 COB LED Totem Display Aging test for UK Customer
Specifications

JC P2.5mm Indoor LED Screen, High Resolution LED Video Wall

Small pixel P2.5mm indoor LED display is very popular now. Currently indoor fixed P2.5 LED display is the most common LED display with pixel pitch in the indoor fixed display market. Specifically designed for HD and high-contrast use where viewers display more vivid pictures and videos. If indoor applications require HD video standards, the P2.5 fixed LED display is the first choice. It is widely used in conference rooms, monitoring rooms, control rooms and other places that require high contrast and close-up viewing.

IP65 Waterproof P2.5 Fixed Indoor LED Display Panel Customized

JCHD JC-P2.5 LED Display
Pixel pitch(mm) 2.5
Pixel Density(dot/m2) 1600000
LED Type SMD2121
Module Size(W x H )mm 320 x 160
Module resolution(W x H) 640 x 480
Module Weight(Kg) 1.3
Power Consumption per Module(w) 50
Diver Mode(Scan) 1/32
Brightness(cd/m2) ≥800
Grey Scale(bits) 16
Refresh Rate(Hz) ≥3,840
Cabinet Size(W x H x D)mm 640 x 480 x 80
Cabinet Weight(Kg/Cabinet) 7.8
Max Power Consumption(W/m2) 605
Average Power Consumption(W/m2) 250
View Angle(H°/V°) 160°/160°
Mini View Distance(m) 2.5
Operating Use Temperature(℃) -10℃~40℃
Storage Use Temperature(℃) -20℃~50℃
Input Voltage(V) 100~240V
Input Power Frequency(Hz) 50Hz~60Hz
Failure Rate ＜1/100,1000
Signal Input Format SDI, RGBHV,YUV,YC,Composite,HDMI,DVI,SD/HD-SDI etc.
Life Time(hrs) 100000
IP Level(front/rear) IP31/IP31
