1080P 4K Aluminum Indoor HD Backlit Display Board Full HD 144hz Monitor
1080P 4K Aluminum Indoor HD Backlit Display Board Full HD 144hz Monitor
1080P 4K Aluminum Indoor HD Backlit Display Board Full HD 144hz Monitor
1080P 4K Aluminum Indoor HD Backlit Display Board Full HD 144hz Monitor
Specifications
Protection Leve :
IP65
Cabinet Size :
640mm*640mm
Module Size :
160mm*160mm
Specification :
Video Wall
Average Power Consumption :
105W per cabinet
Weight :
400g
Warranty :
Two Year
Maintenance :
Front/rear
Cabinet Dimension :
640*480mm/customized
Best View Distance :
3-15m
Tube Chip Color :
SMD Full Color
Cabinet Weight :
5.25kg/3.8kg
Brightness :
≥800cd/m²
Scan Method :
1/32 S
Best Viewing Distance :
≥3m
Place of Origin :
China
Brand Name :
JC
Certification :
CE FCC
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
wooden case，flight case
Delivery Time :
5-7 working days
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
4300 sqm month
Description

Indoor HD display

JC-HD advantages

Aspect ratio: 16:9. various resolution options : 720P; 1080P; 4K; 8K or above.
Low brightness high grey scale:
Redundancy design, back-up power and signal
Die-casting Aluminum, light weight, high precision, good thermal function.
Front maintenance
Silent without fans

Offline Message
Related Case
1080P 4K Aluminum Indoor HD Backlit Display Board Full HD 144hz Monitor
P1.86 Indoor high refresh rate full color advertising LED display
Specifications
JCHD JC-0.8 JC-1 JC-1.25 JC-1.53 JC-1.6 JC-1.8
Pixel pitch(mm) 0.88 1 1.25 1.538 1.666 1.86
Pixel Density(dot/m2) 1265625 1000000 640000 422500 360000 288906
LED Type SMD0606 SMD0808 SMD 1010 SMD1212 SMD1212 SMD1212/ 1515
Module Size(W x H )mm 320 x 160 320 x 160 320 x 160 320 x 160 320 x 160 320 x 160
Module resolution(W x H) 360 x 180 320 x 160 256 x 128 208 x 104 192 x 96 172 x 86
Module Weight(Kg) 1.3 1.3 1.3 1.3 1.3 1.3
Power Consumption per Module(w) 50 50 50 50 50 50
Diver Mode(Scan) 1/45 1/40 1/32 1/26 1/32 1/43
Brightness(cd/m2) ≥600 ≥700 ≥700 ≥700 ≥700 ≥1,000
Grey Scale(bits) 16 16 16 16 16 16
Refresh Rate(Hz) ≥3,840 ≥3,840 ≥3,840 ≥3,840 ≥3,840 ≥3,840
Cabinet Size(W x H x D)mm 640 x 480 x 80 640 x 480 x 80 640 x 480 x 80 640 x 480 x 80 640 x 480 x 80 640 x 480 x 80
Cabinet Weight(Kg/Cabinet) 7.8 7.8 7.8 7.8 7.8 7.8
Max Power Consumption(W/m2) 605 790 580 580 580 440
Average Power Consumption(W/m2) 250 250 250 250 250 250
View Angle(H°/V°) 160°/160° 160°/160° 160°/160° 160°/160° 160°/160° 160°/160°
Mini View Distance(m) 0.8 1 1.3 1.5 1.7 1.8
Operating Use Temperature(℃) -10℃~40℃
Storage Use Temperature(℃) -20℃~50℃
Input Voltage(V) 100~240V
Input Power Frequency(Hz) 50Hz~60Hz
Failure Rate ＜1/100,1000
Signal Input Format SDI, RGBHV,YUV,YC,Composite,HDMI,DVI,SD/HD-SDI etc.
Life Time(hrs) 100000
IP Level(front/rear) IP31/IP31
