XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter 4.5V~40V
XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter 4.5V~40V
XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter 4.5V~40V
XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter 4.5V~40V
XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter 4.5V~40V
XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter 4.5V~40V
Specifications
Brand Name :
XLSEMI
Model Number :
XL1509-5.0E1
Certification :
rohs
Place of Origin :
CN
MOQ :
1
Price :
consult with
Payment Terms :
T/T,Western Union
Supply Ability :
100000
Delivery Time :
5-8days
Packaging Details :
T/R
Chip Type :
DC/DC Power Converter
Operating Voltage :
4.5V~40V
switching frequency :
150kHz
Number of battery cells :
2A
Woridng temperature :
-40℃~+85℃
Static Current (lq) :
2mA
Description
XL1509-5.0E1 2A 150KHz 40V Buck DC/DC Power Converter
4.5V~40V input range, 2A constant output current capability DC/DC power converter
Key Features
  • Wide 4.5V to 40V input voltage range
  • 3.3V, 5V, 12V, and adjustable output versions
  • Output adjustable from 1.23V to 37V
  • Maximum duty cycle: 100%
  • Minimum drop out: 1.5V
  • Fixed 150KHz switching frequency
  • 2A constant output current capability
  • Internal optimized power transistor
  • High efficiency operation
  • Excellent line and load regulation
  • TTL shutdown capability
  • ON/OFF pin with hysteresis function
  • Built-in thermal shutdown protection
  • Built-in current limit function
  • Built-in secondary current limit function
  • Available in SOIC8 package
Applications
  • LCD Monitor and LCD TV
  • Digital Photo Frame
  • Set-up Box
  • ADSL Modem
  • Telecom / Networking Equipment
Pin Description
Pin Number Pin Name Description
1 VIN Supply Voltage Input Pin. XL1509 operates from a 4.5V to 40V DC voltage. Bypass Vin to GND with a suitably large capacitor to eliminate noise on the input.
2 OUTPUT Power Switch Output Pin (SW). Output is the switch node that supplies power to the output.
5~8 GND Ground Pin. Care must be taken in layout. This pin should be placed outside of the Schottky Diode to output capacitor ground path to prevent switching current spikes from inducing voltage noise into XL1509.
3 FEEDBACK Feedback Pin (FB). Through an external resistor divider network, Feedback senses the output voltage and regulates it. The feedback threshold voltage is 1.23V.
4 ON/OFF Enable Pin. Drive ON/OFF pin low to turn on the device, drive it high to turn it off. Floating is default low.
