55 Ultra Narrow Bezel LCD Video Wall Commercial Display
55 Ultra Narrow Bezel LCD Video Wall Commercial Display
Specifications
Model Number :
6255S5
Certification :
FCC CE CCC RoHS ISO 9001
Place of Origin :
China
MOQ :
4
Price :
$ 279 - 293 / Unit
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
Over 8000 Units / Month
Delivery Time :
3-15 Work Days
Packaging Details :
Standard Carton with Foam Cushioning
Brand Name :
YOMURA
Seam :
1.8mm
Size :
55 Inch
Ratio :
16:9
Remote Control Technology :
Infrared
Chromatic Number :
8Bit 16.7M
Input Voltage :
AC 200-240V 50/60HZ
Description
55" Ultra Narrow Bezel LCD Video Wall Commercial Display
55" Ultra-Narrow Bezel LCD Video Wall Commercial Display is engineered for high-end commercial and mission-critical video wall applications. Featuring a 1.8mm ultra-narrow bezel, advanced signal transmission options, and an industrial-grade panel, it delivers exceptional visual continuity, precise color reproduction, and long-term operational stability. It is an ideal solution for control rooms, command centers, and large-scale commercial display projects.
Technical Specifications
Item Specification
Model 6255S5‑(1.8mm)
Screen Size 55 inch
Bezel Width 1.8 mm (combined)
Resolution 1920 × 1080
Backlight Type Direct LED (OD35)
Brightness 420 cd/m² ±30
Contrast Ratio 4000:1
Response Time 6.5 ms
Refresh Rate 60 Hz
Viewing Angle 178° (H) / 178° (V)
Color Gamut 75%
Color Depth 8‑bit, 16.7M colors
Uniformity 88%
Operating Time 24/7
Panel Orientation Landscape / Portrait
Panel Lifetime ≥50,000 hours
Interface & Control
Interface Description
HDMI Input 1 × HDMI, up to 3840×2160 @30Hz
RJ45 Video Input 1 × Network video input (up to 50m @1080p)
RS232 RJ45 RS232 IN/OUT for control & debugging
USB 1 × USB 2.0 (upgrade & media playback)
Audio Output Supported
Power & Environment
  • Power Supply: AC 200-240V, 50/60Hz
  • Max Power Consumption: ≤138W
  • Standby Power: <0.3W
  • Operating Temperature: 0°C - 45°C
  • Storage Temperature: ‑20°C - 50°C
Product Highlights
55
Ultra‑Narrow 1.8mm Bezel Design
  • Combined bezel width of only 1.8mm
  • Minimizes visual separation between panels
  • Creates a nearly seamless large-format video wall
55
Dual Signal Transmission: RJ45 + HDMI
  • Supports HDMI and network (RJ45) video transmission
  • Network signal reduces cabling cost and simplifies installation
  • Compatible with network video distributors and matrices
55
Accurate Color & Wide Color Gamut
  • 75% color gamut with precise color calibration
  • Natural color reproduction suitable for exhibitions and conference environments
  • Consistent image quality across multiple panels
55
Anti‑Glare & Wide Viewing Angle
  • Matte anti‑glare panel reduces reflections
  • 178° horizontal and vertical viewing angle
  • Maintains color consistency from different perspectives
