Specifications
Brand Name :
Johnson Tools
Model Number :
600mm
Certification :
SGS, GB
Place of Origin :
China
MOQ :
5 pcs
Price :
Negotiate
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100000 pcs per year
Delivery Time :
Around 15-35 days
Packaging Details :
White box
Product Name :
Laser Welded Diamond Saw Blade
Manufacturing Process :
Laser welding
Outer diameter :
600mm
Application :
Cutting reinforced concrete
Inner hole :
25.4mm, 50mm or as your request
Segment thickness :
4.4mm
Segment height :
10/12/15mm
Color :
Clear or as your request
HS code :
8202391000
Description

1. Description of 600mm Diamond Saw Blade with Good Sharpness for Reinforced Concrete

600mm diamond concrete saw blades is mainly used for the situations which contained reinforced concrete, like cutting new and old road expansion joints and bridge parapet ripper dressing.

Design different segment formula for different power machines, different hardness, different wear resistance, etc. Apply to different construction materials cutting.

Well exported to Australia and Asia, Europe, America, Africa, market.

2. Feature of 600mm Diamond Saw Blade with Good Sharpness for Reinforced Concrete


1) Fast speed, high efficiency for cutting reinforced concrete structure.
2) The kerf is very smooth and flat, surface is very pretty.
3) Concrete cutting is no vibration, have no influence for previous structure.
4) Reinforced concrete cutting is no dust, low noise, it is a good environment.
5) Well precision construction.

3. Specification of 600mm Diamond Saw Blade with Good Sharpness for Reinforced Concrete


Diameter:600mm
Segment thickness:4.4mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm as your request

Inch Diameter
(mm)		 Teeth length
(mm)		 Teeth thickness
(mm)		 Teeth height
(mm)		 Teeth number
(nos)
24" 600 40 4.4 10 42
24" 600 40 4.4 12 42
24" 600 40 4.4 15 42

600mm Laser Welded Diamond Saw Blade Reinforced Concrete Cutting Disc


Other size Concrete Saw Blade we could do as following

Inch Diameter
(mm)		 Teeth length
(mm)		 Teeth thickness
(mm)		 Teeth height
(mm)		 Teeth number
(nos)
4" 105 32 2.2 7/10/12 8
4.5" 115 31 2.2 7/10/12 9
5" 125 31 2.2 7/10/12 10
6" 150 34 2.2 7/10/12 11
7" 180 34 2.4 7/10/12 14
8" 200 40 2.4 7/10/12 13
9" 230 37 2.6 7/10/12 16
10" 250 40 2.6 10/12/15 16
12" 300 40 3.0 10/12/15 20
14" 350 40 3.2 10/12/15 24
16" 400 40 3.4 10/12/15 28
18" 450 40 3.6 10/12/15 32
20" 500 40 4.0 10/12/15 36
26" 650 40 4.4 10/12/15 42
28" 700 40 5.0 10/12/15 40


4. Packing and Shipping

Each 24" laser saw blade is packed in white box, then 5pcs put in an export standard carton, gross weight per carton is limited within 45kg.

Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.

Delivery way: By air, by sea, by land, by courier, etc.
