Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting
Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting
Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting
Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting
Specifications
Brand Name :
Xianda Machinery
Model Number :
SHKB-21500C
Certification :
API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Place of Origin :
Jinjiang, Fujian, China
MOQ :
1 Set
Price :
To Be Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Sets/Year
Delivery Time :
15 Days
Packaging Details :
Wire rope lashing,Suitable for sea/air/land/rail transportation.
Trademark :
XIANDA
Model No :
SHKB-21500
Max Cutting Width :
1500mm
Outline Dimension :
4000 x 7100 x 2600mm
Gross Weight :
5000kg
Cutting Accuracy :
High Accuracy
Gross Power :
18.5kw x 2/22kw x 2 (Optional)
Transport Package :
Load in a 20 Feet Container
Description

SHKB-21500 Double-Blade Automatic Edge Trimming Machine

Gantry-Type, Trolley-Driven Micro-Computer Edge Processor for Marble, Granite, Arc Kerb & Tombstone

Quick Specs

Parameter Unit HKB-21500C
Blade diameter mm 600~800
Worktable size mm 1000 x 2500
Front-to-back travel mm 2500
Cutting head lifting stroke mm 500
Max processing width (Vertical Cut) mm 1500
Cutting head rotation degree ° ±45° (Electric control)
Main motor power kw 18.5kw x 2/22kw x 2 (Optional)
Total power kw 44/51
Outline dimensions mm 4000 x 7100 x 2600
Total weight kg ≈5000
Water consumption m³/h ≈4

Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting


Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting

Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting

Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting

Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting

Double-Blade Automatic and Automatic Gantry-Fixed Edge Trimming Machine for Stone Edge Cutting

Product Overview

The SHKB-21500 is a gantry-fixed, trolley-moving, double-blade edge trimmer driven by full-electric microcomputer control.
Steel-wire rope transmission eliminates blade jamming under overload, delivering higher cutting efficiency, superior flatness, and longer blade life while reducing labor and energy costs. Ideal for edge cutting and chamfering of marble, granite, arc kerbstones, and tombstones.

Key Equipment Features

1. Micro-Computer + Full-Electric Control

  • The one-touch program stores edge length, chamfer angle and feed rate
  • No hydraulics → cleaner workshop
  • Remote diagnostic port for on-line support

2. Gantry-Fixed / Trolley-Moving Design

  • 15 m effective travel (extendable) → single-pass trimming of long kerbs or tombstone borders
  • The gantry frame absorbs vibration
  • Open front & rear → forklift loading, automatic in-line connection to polishing line

3. Steel-Wire Rope Transmission

  • The overload slip protects blades from jamming when hitting hard veins

Workflow Advantage

  1. Load stone onto moving trolley (forklift or vacuum lifter)
  2. Select program
  3. Press START – trolley advances, both blades trim simultaneously
  4. Unload finished piece – ready for next process
One operator, zero manual pushing, 10× faster than hand-held machines.

Package & Warranty

  • Export crate: wire rope lashing, suitable for sea/air/land/rail transportation.
  • Delivery: 20 days (standard), 30 days (custom length)
  • Warranty: 12 months for parts
  • Installation: video-guide + remote support; on-site service optional
  • Spare parts: 72 h dispatch from regional warehouse
