FANUC A02B-0303-C234 Main Panel B Machine Operator Panel

Product Overview

The FANUC A02B-0303-C234 is a machine operator panel identified as Main Panel B. It is publicly associated with FANUC FS30, FS31 and FS32i CNC control systems.

This panel provides physical operator keys and machine-control inputs for daily CNC operation. Depending on the machine-builder configuration, these controls may be used for mode selection, cycle commands, reset, machine-function selection and other assigned operations.

Key Product Features

• Main Panel B machine operator-panel configuration
• Physical operator keys for CNC machine control
• Associated with FANUC FS30, FS31 and FS32i systems
• Panel-mounted industrial operator interface
• Designed for replacement of an existing matching panel

Technical Identification

Typical Applications

• CNC machining-center control panels
• CNC turning and milling machine operator stations
• Replacement of damaged keys or complete operator-panel assemblies
• Maintenance of FANUC 30i, 31i and 32i machine installations

Related and Nearby Models

Related A02B-0303 machine-panel and MDI references include A02B-0303-C231, A02B-0303-C233, A02B-0303-C234, A02B-0303-C238 and A02B-0303-C328.

These panels can differ in Main Panel designation, key assignments, key language, symbol layout, CNC generation, mounting dimensions, internal circuit boards and rear connector arrangement. A neighboring number may look similar from the front while using a different key map or electrical interface.

A02B-0303-C231 and A02B-0303-C234 should therefore be maintained as separate products. C233, C238 and C328 are useful family search terms, but they are not confirmed replacements for C234.

Ordering Checklist

• Confirm the exact model A02B-0303-C234.
• Compare the complete front key arrangement.
• Verify the key language and machine-function symbols.
• Check all rear connectors and mounting dimensions.
• Confirm whether the display or other panel sections are included.

Supply Condition Notice

The product may be supplied as new, new-surplus, refurbished or used. The condition, included boards, keys, mounting hardware and warranty must be stated separately in the commercial quotation.
