698-2700MHz 4G LTE MIMO Panel Antenna 9dBi Indoor Outdoor Patch Panel Antena
698-2700MHz 4G LTE MIMO Panel Antenna 9dBi Indoor Outdoor Patch Panel Antena
Specifications
Brand Name :
Deertom
Model Number :
DT-PA698-2700-9-2B
Certification :
CE,RoHS
Place of Origin :
China
MOQ :
50pieces
Price :
10
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
500pcs per day
Delivery Time :
7
Packaging Details :
Neutral
Frequency :
698-2700MHz
Gain :
9dBi
Type :
MIMO
Description
ELECTRICAL
Model DT-PA698-2700-9-2B
Frequency Range 698-960/1710--2700MHz
Gain 8/9*2dBi
Beamwidth H: 79±5° , E: 68±5°
VSWR ≤1.8
Polarization Vertical and Horizontal or ±45°
F/B Ratio ≥13dB
Isolation ≥25dB
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female*2 or customized
Antenna Dimension 280*180*60mm
Weight 0.75kg
Radome Material Waterproof ABS
Working Temperature -40℃~﹢65℃
Antenna Color White
Rated Wind Velocity 60m/s
Pole Diameter Φ35-55mm
Rated Wind Velocity 210 km/h
