Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Specifications
Brand Name :
Hima
Model Number :
F6217
Place of Origin :
Germany
MOQ :
1
Price :
66USD
Payment Terms :
T/T
Supply Ability :
in stock
Delivery Time :
2-3 work days
Packaging Details :
Brand new and original
INPUT RESISTANCE :
100 KOHM
RESOLUTION :
12 BITS
Place of shipment :
Xiamen, China
weight :
0.14 kg
Input voltage :
0...5.5 V
max. input voltage :
7.5 V
Input current :
0...22 mA (via shunt), 22 mA = 4095
max. input current :
30 mA
Description
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Product Model F6217
Product Parameters ANALOG INPUT BOARD/MODULE
Place of shipment Xiamen, China
Estimated Shipping Size 2x19x12.8cm
R*: Shunt with 250 Ω; 0.05 %; 0.25 W
Current input T<10 ppm/K; part-no: 00 0710251
Resolution 12 bit, 0 mV = 0, 5.5 V = 4095
Measurand update 50 ms
Safety time < 450 ms
Input resistance 100 kΩ
Electric strength 200 V against GND
Space requirement 4 SU
Operating data 5 VDC / 80 mA, 24 VDC / 50 mA
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Module Features

The module incorporates a redundant, safety-related processor system, enabling self-testing directly on the module. All tests are executed internally; detected errors are flagged for user evaluation.

Main Test Routines
  • A/D Converter Linearity: Verify accuracy across the input range.
  • A/D Converter Overflow: Detect numerical saturation conditions.
  • Channel Cross-Talk: Check interference between the eight input channels.
  • Input Filter Function: Confirm proper signal conditioning.
  • I/O Bus Communication: Validate data transfer integrity.
  • Microcontroller Self-Tests: Verify core processor functionality.
  • Memory Tests: Check program and data memory integrity.
Error Handling
  • Any recognized error sets the channel error bit.
  • Evaluation and response must be implemented within the user program.
Hima F6217 Analog Input Module with 12-bit Resolution 100 kΩ Input Resistance
Warranty Policy
  • Each part has a one-year warranty.
  • Warranty terms may vary based on supplier agreements.
Shipping Carriers
  • Standard carriers: FedEx, UPS, DHL, USPS.
  • Customer's preferred carrier can be used.
  • Alternative carriers available for convenience.
Payment Methods
  • Bank transfer accepted.
  • Chinese Yuan (RMB) available if using a shipping forwarder or contact in China.
