Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
Specifications
Brand Name :
CSJY
Model Number :
MBC2406
Certification :
CE
Place of Origin :
China
MOQ :
2
Price :
according to quantities
Payment Terms :
T/T
Supply Ability :
5000pcs/month
Delivery Time :
7 working days
Packaging Details :
cartons
Power supply :
DC24V
Current :
6.5A
Communication mode :
RS232 serial communication, supporting Modbus protocol
Infrared sensor :
6 independent interfaces, PNP, NPN normally open, open collector type
Adaptor motor :
DC brushless motor below 60W with 2400-line position feedback
Application :
swing gate, speed gate, flap gate, sliding gate or tripod turnstile
Voice output :
external 8W 4Ω speaker
Working environment :
-20℃ ~ 55℃, humidity below 90% (no condensation)
Description

Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate


Product introduction:

This system consists of access gate control board, brushless servo motor, servo control technology, real-time detection of motor position, self-learning load curve without external encoder, physical anti-pinch protection and adjustable sensitivity. Support access mode settings such as card swiping, freedom and prohibition at the entrance and exit;It has the logic detection of illegal intrusion, trailing traffic, detention, reverse traffic, infrared anti-pinch, etc., and is suitable for access gate equipment such as speed gate/swing gate, flap gate/sliding gate, etc.


Functional characteristics:

MBC2406 brushless servo solution

Ordinary brushless solution

Adapting motor

Brushless motor with 2400 line position feedback

Ordinary DC brushless motor

Anti-pinch protection

Current+position double detection, adjustable sensitivity

No encoder, low anti-pinch sensitivity

Control effect

The switch speed is fast, and it is stable and does not shake.

Deceleration is obvious and there is shaking.


Technical parameter:

① Input power supply: DC24V, dual power connection, 150W/6.5A on one side is recommended; Single power connection, 300W recommended;

② Adaptor motor: DC brushless motor below 60W with 2400-line position feedback;

③ Communication mode: RS232 serial communication, supporting Modbus protocol;

④ Power-off: DC12V battery, or optional super capacitor module;

⑤ Working environment: -20℃ ~ 55℃, humidity below 90% (no condensation)

⑥ Infrared sensor: 6 independent interfaces, PNP, NPN normally open, open collector type;

⑦ Voice output: external 8W 4Ω speaker.


Application:

Control Board Support 6 Pairs Sensors PNP NPN for Full-automatic Tripod Turnstile Gate
