480V Prefabricated Data Center Container Solutions Server Modules
480V Prefabricated Data Center Container Solutions Server Modules
480V Prefabricated Data Center Container Solutions Server Modules
480V Prefabricated Data Center Container Solutions Server Modules
480V Prefabricated Data Center Container Solutions Server Modules
480V Prefabricated Data Center Container Solutions Server Modules
Specifications
Place of Origin :
China
Brand Name :
Soeteck
Certification :
CE, ISO, UL
MOQ :
1
Price :
To Be Negotiated
Packaging Details :
20/40ft High Cube Container
Delivery Time :
5-10 Weeks
Supply Ability :
10000/Month
Model Number :
SYICDC
Payment Terms :
L/C,D/A,D/P,T/T
Deployment Time :
5-10 Weeks
Rack Quantity :
4/9/12 pcs
Single Rack Capacity :
42U
Single Rack Max. Capacity :
6kW
Power Sypply :
15kVA*6, N+1 Modular UPS
Cooling Type :
In Row Pricision AC/ Liquid Cooling
Rack Dimensions (W*D*H) :
600*1100*2000mm
Applications :
Edge Computing, Remote Sites, Disaster Recovery
Monitoring System :
Yes
Door Security System :
Yes
EPO :
Yes
Video Monitoring System :
Yes
Description

For projects where standard ISO containers simply do not fit, SOETECK offers Customized Non-Standard Container Data Centers. Whether you require extra width for wider server racks, spliced containers for massive internal halls, or reinforced plating for corrosive coastal areas, our R&D team can engineer a solution tailored to your exact specifications.

We move beyond "off-the-shelf." From altering the physical dimensions (e.g., 10ft mini-modules or extra-wide 3.5m units) to integrating specialized power inputs (380V/480V, 50Hz/60Hz) and advanced cooling options like Liquid Cooling for AI clusters, we ensure the infrastructure adapts to your business, not the other way around.


Product Family

Model No. Container Size Total Capacity Rack Qty Single Rack Load UPS Configuration Cooling
ICDC20 › 20' HQ (ISO) 54 KW 9 Racks Max 6 KW 90 kVA Modular (N+1) In-Row
ICDC40-A › 40' HQ (ISO) 24 KW 4 Racks (Spacious) Max 6 KW 45 kVA Modular (N+1) In-Row
ICDC40-B › 40' HQ (ISO) 72 KW 12 Racks Max 6 KW 120 kVA Modular (N+1) In-Row
Customized › Non-Standard Up to 500 KW Flexible Up to 20 KW+ Custom Redundancy In-Row / Liquid

Product Features

480V Prefabricated Data Center Container Solutions Server Modules

Structural & Material Flexibility

We support assembled cabinets and non-standard welding dimensions. Options include "Spliced" designs where multiple containers join to form a large server hall, or specialized anti-corrosion paint and 10-fold profile welded frames for oil rigs and maritime applications (C5-M corrosion standards).


Extreme Power & Liquid Cooling

Future-proof your infrastructure for AI and Crypto Mining. We offer customization for high-wattage racks (>20kW) using Direct-to-Chip liquid cooling or Immersion cooling integration, achieving PUE values below 1.1. We also customize voltage inputs for different global regions (e.g., US 480V vs EU 400V).

480V Prefabricated Data Center Container Solutions Server Modules

FEATURED PRODUCTS OF DATA CENTER SOLUTIONS


Tailored to diverse deployment scenarios—including small enterprise IT rooms, retrofitted traditional data centers and outdoor edge nodes—our modular data center solutions balance performance, cost and energy efficiency.

480V Prefabricated Data Center Container Solutions Server Modules

3-15 kW per Cabinet

Micro Data Center

All-in-one integrated cabinet design, plug-and-play deployment (1-3 days), remote intelligent monitoring. Ideal for edge endpoints like retail stores, ATMs and small enterprise IT rooms.

480V Prefabricated Data Center Container Solutions Server Modules

8-30 kW per Cabinet

Row Modular Data Center

Column-level prefabricated design, flexible expansion by rows, fits existing server rooms without major reconstruction. PUE 1.2-1.4, perfect for medium-density enterprise IT deployments.

480V Prefabricated Data Center Container Solutions Server Modules

15-40 kW per Cabinet

Aisle Containment Data Center

Airtight cold/hot aisle enclosure, 90%+ cold air utilization, PUE reduced to 1.2-1.3. Cost-effective upgrade for traditional open data centers to support high-density servers.

480V Prefabricated Data Center Container Solutions Server Modules

10-500 kW (20ft/40ft)

Container Data Center

Prefabricated all-in-one container (20ft/40ft), dustproof/anti-vibration, deployable outdoors. Liquid cooling optional for AI high-density computing (PUE ≤1.1), ideal for edge & temporary computing needs.

APPLICATIONS


Empowering next-generation infrastructure with superior thermal management for high-wattage computing demands.

480V Prefabricated Data Center Container Solutions Server Modules
AI Training & HPC Clusters
480V Prefabricated Data Center Container Solutions Server Modules
High-Density Data Centers
480V Prefabricated Data Center Container Solutions Server Modules
Modular & Container Solutions
480V Prefabricated Data Center Container Solutions Server Modules
Blockchain & Crypto Mining

FAQ


1. What are the primary applications for Container Data Centers?
Container Data Centers (CDCs) are ideal for rapid capacity expansion, disaster recovery, and edge computing. They are widely used in remote oil & gas sites, military operations, large-scale sporting events, and as modular building blocks for hyperscale data centers.
2. What are the key advantages over traditional data centers?
The main benefits include speed of deployment (weeks instead of years), mobility, and scalability. Because they are factory-pre-integrated and tested, they minimize on-site construction risks and offer a "pay-as-you-grow" financial model.
3. How do containers withstand harsh outdoor environments?
CDCs are built using ruggedized ISO steel enclosures with high-grade insulation and IP55/IP65 ratings. They are designed to operate in extreme temperatures (from -40°C to +55°C) and feature specialized coatings to resist corrosion, salt spray, and sandstorms.
4. Are Container Data Centers energy efficient?
Yes. By using contained cold/hot aisles and close-coupled cooling (In-Row), CDCs significantly reduce energy waste. This precision cooling allows many units to achieve a Power Usage Effectiveness (PUE) as low as 1.15 to 1.3, making them more efficient than many traditional facilities.
5. What internal systems are included in a standard unit?
A standard CDC is an all-in-one solution including power distribution (UPS/ATS), cooling systems, fire suppression (FM200 or Novec 1230), smart environmental monitoring (DCIM), and physical security/access control systems.
