Chilled Water Cold Aisle Containment Data Center Architecture Large Scale
Chilled Water Cold Aisle Containment Data Center Architecture Large Scale
Specifications
Brand Name :
Soeteck
Model Number :
1
Certification :
CE, ISO, UL
Place of Origin :
China
MOQ :
1
Price :
To Be Negotiated
Payment Terms :
D/A
Supply Ability :
10000/Month
Delivery Time :
5-10 Weeks
Packaging Details :
Wooden
Total Racks :
<48
Power Input :
380V, 50/60HZ
Single Rack Capacity :
42U
Single Rack Max. Capacity :
<15kW
Power Sypply :
<500kVA, N/N+1/2N
Available U Space :
On Demand
Cooling Type :
In-Row Precison ACs, Fan Wall or Liquid Cooling
Cooling Capacity :
On Demand
Communication Ports :
USB, RS-232, or Network Management Card
Applications :
Edge Computing, Large-Scale Data Center
Description

Overcome architectural constraints with our Customized Modular Data Center Solutions. Tailored for unique facility footprints and ultra-high-performance requirements, this service allows for the configuration of up to 48 cabinets with flexible aisle widths and heights. Whether you are retrofitting an irregular room or deploying a Tier IV mission-critical facility, our engineering team adapts the containment to your exact specifications.

Future-proof your infrastructure with advanced cooling options beyond standard air systems. Our custom solutions support Chilled Water and Direct-to-Chip Liquid Cooling integration, enabling extreme power densities of up to 15kW+ per rack for AI training and supercomputing. We offer fully redundant 2N power architectures to meet the most stringent uptime requirements of telecom and financial sectors.


Product Family

Configuration IT Cabinets Power / Cab UPS System Cooling Capacity Refrigeration Type Dimensions (L*W*H)
Plan 1 › 12 Cabinets 5 kW 90K Rack Modular
(15kVA modules, 4+1)		 25.5kW x 4
(3+1 Redundancy)		 In-Row AC 4200 x 3600 x 2000 mm
Plan 2 › 12 Cabinets 5 kW 120K Tower Modular
(30kVA modules, 3+1)		 65.5kW x 2
(1+1 Redundant)		 In-Row AC 4800 x 3600 x 2000 mm
Plan 3 › 14 Cabinets 5 kW 120K Tower Modular
(30kVA modules, 3+1)		 71.1kW x 1
(N Redundancy)		 Room-Level AC 4800 x 3600 x 2000 mm
Plan 4 › 14 Cabinets 5 kW 120K Tower Modular
(30kVA modules, 3+1)		 Custom Capacity
(Tailored)		 FAN WALL 4800 x 3600 x 2000 mm
Plan 5 › 18 Cabinets 5 kW Modular N+1
(25kVA modules, 4+1)		 31.1kW x 4
(3+1 Redundancy)		 In-Row AC 6000 x 3600 x 2000 mm
Plan 6 › 24 Cabinets 5 kW Modular N+1
(25kVA modules, 5+1)		 40.9kW x 4
(3+1 Redundancy)		 In-Row AC 8400 x 3600 x 2000 mm
Custom › ≤ 48 Cabinets ≤ 15 kW Max 500kVA
(2N/N+1 Redundancy)		 Flexible Capacity
(Row or Room)		 Air / Water / Chilled Length ≤ 15000 mm

Product Features

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale

Limitless Architectural Adaptability

Tailored Dimensions: Unlike rigid standard modules, we customize aisle width, height, and length (up to 48 racks) to fit irregular room shapes, low ceilings, or existing support pillars.
Retrofit Friendly: Designed to deploy rapidly in repurposed warehouses or office spaces without requiring raised floors or extensive building modifications.


Future-Proof Cooling Ecosystem

Beyond Air Cooling: Compatible with Chilled Water and Direct-to-Chip Liquid Cooling loops to support next-gen GPU clusters with densities >15kW/rack.
Hybrid Deployment: Support hybrid cooling architectures (Air + Liquid) within the same containment system to bridge the transition from legacy to AI infrastructure.

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale

Full Series OF HIGH-DENSITY DATA CENTER SOLUTIONS


Focus on the core cooling demands of high-density data center deployments, where our full range of premium products leverages advanced technological advantages to reliably safeguard continuous, efficient, and stable operation.

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale

5-30 kW per Cabinet

Cold Aisle Data Center

Airtight cold aisle enclosure, 90%+ cold air utilization rate, PUE ≤ 1.2, fast deployment and flexible expansion for medium-density IT loads.

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale

10-80 kW Total Power

20ft Container DC

Prefabricated all-in-one design, anti-vibration & dust-proof, plug-and-play, ideal for edge computing and temporary computing demand scenarios.

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale

30-100 kW per Cabinet

40ft Cold Plate Container DC

Hybrid air-liquid cooling, direct heat dissipation from GPU/CPU, AI-ready design, high power density with low energy consumption.

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale

50-200 kW per Cabinet

40ft Immersion Container DC

Immersion cooling with dielectric fluid, 100x higher heat dissipation efficiency than air cooling, PUE ≤ 1.1, perfect for ultra-high density AI clusters.

APPLICATIONS


Empowering next-generation infrastructure with superior thermal management for high-wattage computing demands.

Chilled Water Cold Aisle Containment Data Center Architecture Large Scale
AI Training & HPC Clusters
Chilled Water Cold Aisle Containment Data Center Architecture Large Scale
High-Density Data Centers
Chilled Water Cold Aisle Containment Data Center Architecture Large Scale
Modular & Container Solutions
Chilled Water Cold Aisle Containment Data Center Architecture Large Scale
Blockchain & Crypto Mining

FAQ


1. Can you design a module for an irregularly shaped room?
Absolutely. We specialize in bespoke containment. We can adjust aisle widths, cabinet heights, and even create L-shaped or split-row configurations to navigate around building pillars or obstacles.
2. Is this solution compatible with liquid cooling servers?
Yes. We can integrate CDUs (Coolant Distribution Units) and manifold piping within the custom racks to support Direct-to-Chip liquid cooling for next-gen AI hardware.
3. What is the standard lead time for international delivery?
For standard models (12/18/24/30/Customized racks), production typically takes 25-60 days. For customized solutions, the lead time is approximately 45 days after design approval. We ship globally in reinforced, fumigation-free wooden crates.
4. Do you provide on-site installation services?
We provide comprehensive installation manuals and 24/7 video technical support. For large-scale projects, we can dispatch engineers to your site for installation guidance and commissioning upon request.
5. What certifications do your data centers hold?
Our manufacturing facilities are ISO 9001/14001 certified. The modular data center components (UPS, Cooling, PDU) comply with CE, UL, and TIER-ready standards, ensuring global regulatory compliance.
