Specifications
Place of Origin :
JIANGSU, CHINA
Brand Name :
TONGDA
Packaging Details :
PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
Supply Ability :
800sets/year
Price :
$21,999.00 - $29,999.00/Sets
Certification :
CE, ISO9001
MOQ :
1SET
Delivery Time :
28 working days
Payment Terms :
T/T, L/C, D/P, West Union
Model Number :
TONGDA HTS2L
Core Components :
PLC, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Plastic Processed :
PP, HDPE, PC, ABS, PVC, PE, EVA, PA, ABS/PP, PE/PP, HDPE/PP, PETG
Year :
2020
Voltage :
Customized to customer needs
Dimension(L*W*H) :
3.2m*2.12m*2.55m
Hollow part volume :
1-2L
Clamping Force (kN) :
44
PLC Brand :
MITSUBISHI
Screw L/D Ratio :
25
Screw diameter (mm) :
60 mm
Output (kg/h) :
60 kg/h
Automation :
Automatic
No. of Screw Heating Zone :
3
Screw Heating Power(kW) :
11.2 kW
Extruder Motor Power(kW) :
15 kW
Mold Platen Size(Width)(mm) :
360 mm
Mold Platen Size(Height)(mm) :
320 mm
Air Pressure(MPa) :
0.6 MPa
Air Comsumption(m³/min) :
0.4 m³/min
Die Head Heating Power(kW) :
7 kW
Accumulator Capacity(L) :
0 L
Power (kW) :
39
Weight (T) :
6
Key Selling Points :
Long Service Life
Warranty :
1 Year
Applicable Industries :
Energy & Mining, Hotels, Home Use, Machinery Repair Shops, Restaurant, Food & Beverage Factory, Farms
Showroom Location :
Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria
Rotary Cylinder Brand :
FESTO
Station :
Single Station
Suitable bottle :
1-2L
Key words :
Automatic Extrusion Blow Moulding Machine
Use :
Hollow Moulding
Parison Control :
MOOG
Max. Size of Mold :
360*320
Description

TONGDA HTS2L Single Station Fully Automatic Mini Extrusion Blow Molding Machine

Product Description

This machine is suitable for the small bottles.The main parts of this machine are designed and manufactured by ourself.E.g:continuous die head / HDPE plastic additive bottle car brake oil can

Technical Parameters

MODEL Units HTS-2L Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume L 5
Output of HDPE kg/h 50
Clamping force kn 44
Screw diametre mm 50
Screw heating power kw 6.8
Blow pressure mpa 0.6
Size of machine m 2.78*1.55*2.35

Product Details

Stable and efficient clamping system

Adjustable rotary type blow pin unit, suitable for oblique bottles

Parison controller we use MOOG 200 Points or AUTOMATA 300 Points, with extremely sensitive action.

Touch screen we use large size INNOVANCE

Company Information

Suzhou Tongda Machinery Co., Ltd. is located in Zhangjiagang City, Fenghuang town Korea Industrial Park. 2 hours away from Shanghai City by car. We have more than 23 years experience always specialized in R&D and manufacturing of extrusion blow molding machine.

After-sales services

During epidemic period, our team have helped customers start up more than 250sets new Tongda machines by online service, to help customer run the machine as soon, our after sales team helped around 3 hours till the mid-night.

FAQ

Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of auxiliary equipment.
5. A free 2-day training course will be provided to customers every year.
6. Special processing equipment to produce after-sales accessories to ensure rapid response to user needs.


Q: How big is your company?
A: our company has 400 employees and A building area of 100,000 square meters. We own land and factories.The company has a registered capital of us $2 million and a long-term business license since 1999.
