Bentley Nevada 330400-01-05 Accelerometer 1/4-28 UNF Integral Stud Multiple Approvals

1, Product Overview
The 330400-01-05 is the standard model of the reverse mount probe in the Bently Nevada 3300 XL series, compatible with the 3300 XL 8 mm eddy current vibration monitoring system. This probe features a high-temperature and corrosion-resistant PPS molded head, ensuring long-term stable operation in harsh industrial environments such as oil mist, humidity, and dust. It provides high-precision radial vibration, axial displacement, and key phase signals for rotating machinery such as turbines, compressors, pumps, fans, and gearboxes.

2, Key Features
• Reverse-mount design: The probe threads are located at the rear of the housing, allowing installation from inside the device, eliminating space constraints.
• Coaxial cable length: 1 m (05 code)
• Connector type: Micro ClickLoc™ coaxial connector with a 45° boot, anti-loosening and oil-resistant
• Electrical length calibration: Compatible with 330180-AXX-BXX proximitor sensors, with a system linear range of 2 mm (80 mils)
• Temperature range: Probe tip –35°C to +260°C; cable –51°C to +200°C
• Ingress protection: IP68 (probe head), oil- and chemical-resistant
• Certifications: ATEX/IECEx Zone 2, CE, UL, CSA, UKCA, EAC

3, Technical Parameters
Probe type: 330400 reverse-mount probe
Total coaxial cable length: 1 m
Thread size: 3/8-24 UNF-2A reverse mount
Housing material: AISI 303 stainless steel
Head material: PPS thermoplastic
System sensitivity: 7.87 V/mm (200 mV/mil) ±5 %
Frequency response: 0 … 10 kHz (–3 dB)
Linearity error: < ±0.025 mm (1 mil)

4, Available cable lengths:
01 = 1 m (05) | 05 = 5 m (15) | 10 = 10 m (25)
Please specify in your order if explosion-proof armor or stainless steel braided sheath is required.
