Cassette Type Plastic Insertion Module 1*64 PLC Splitter 130*101*206mm
Cassette Type Plastic Insertion Module 1*64 PLC Splitter 130*101*206mm
Cassette Type Plastic Insertion Module 1*64 PLC Splitter 130*101*206mm
Cassette Type Plastic Insertion Module 1*64 PLC Splitter 130*101*206mm
Specifications
Brand Name :
GEZHI or OEM
Model Number :
PLC Splitter Cassette
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1 pieces
Price :
US$59-US$118
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Day
Delivery Time :
7 Days
Packaging Details :
inner box,Carton
Storage Temperature :
-40℃~+85℃
Operating Temperature :
-20℃~+70℃
Split Ratio :
50/50
Polishing Type :
APC/UPC
Connector Type :
SC/LC
Fiber Type :
Single Mode
Description

Product description

1*64 PLC Splitter 130*101*206mm Cassette Type Plastic Insertion Module

The PLC Splitters is branching devices that is used to distribute optical signals to multiple locations for processing. In optical networks, it is often necessary to split an optical signal into many identical signals, or to combine many signals into a single signal. PLC Splitter (Planar lightwave circuit splitter) is a type of optical power management device that is fabricated using silica optical waveguide technology. They are designed for FTTx Passive Optical Networks, CWDM, DWDM and optical cable TV System. PLC Splitter is responsible to distribute optical signals from Central Office (CO) to multiple premise locations.We provides whole series of 1*N and 2*N splitter products that are tailored for specific applications.

Cassette Type Plastic Insertion Module 1*64 PLC Splitter 130*101*206mm

Cassette Type Plastic Insertion Module 1*64 PLC Splitter 130*101*206mm

Feature

1. Loss is not sensitive to the wavelength of light, and can meet the transmission needs of different wavelengths.

2. The light is evenly distributed, and the signal can be evenly distributed to users.

3. The structure is compact and the volume is small, it can be directly installed in the existing various transfer boxes without leaving a large installation space.

4. There are many shunt channels for a single device, which can reach more than 32 channels.

5. Wide operating wavelength

Specification

Port Configuration 1×64
Operating Wavelength (nm) 1260~1650
Insertion Loss (dB) Typ. 20.0
Max. 21.5
Loss Uniformity (dB) Typ. 1.5
Max. 2.5
Return Loss (dB) 55
PDL (dB) Typ. 0.2
Max. 0.4
Directivity (dB) 55
Fiber Type SM G.657A1
Wavelength Dependent Loss (dB) Typ. 0.3
Max. 0.5
Temperature Stability (-40~+85°C) (dB) Typ. 0.4
Max. 0.5
Operating Temperature (°C) -40~+85°C
Storage Temperature (°C) -40~+85°C

Test Enviroment
NO-dust workshop
High Temp. Ageing & High-Low Temperature cycling
Relay Reliable Testing
100% Testing Before Shipment

FAQ
Q1:Can I have a sample order? What is your MOQ for PLC Splitter Cassette?
A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What's the Lead time for PLC Splitter Cassette?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms?
A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
Q4: What is your warranty time for PLC Splitter Cassette?
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
