Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Specifications
Brand Name :
GEZHI or OEM
Model Number :
Fixed Fiber Optic Attenuator
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1pc
Price :
US$0.8/PCS-US$20/PCS
Payment Terms :
T/T,Western Union
Supply Ability :
5000pcs per month
Packaging Details :
Paper box
Fiber Connector :
MU/UPC
Ferrule Type :
Zirconia Ceramic
Connector Gender :
Fixed Male to Female
Transfer Mode :
Singlemode
Attenuation :
1~25dB
Operating Wavelength(nm) :
1260~1620(SM)
Attenuation Accuracy :
1-5dB ±0.5, 6-10dB ±0.7, >10dB ±1.0
Return Loss :
≥50dB
Polarization Dependent Loss :
≤0.2dB
Max Optical Input Power :
200mW
Humidity :
95%RH
Operating Temperature Range :
-40 to 80°C (-40 to 176°F)
Storage Temperature Range :
-40 to 85°C (-40 to 185°F)
Description
Customized MU/UPC Single Mode Fiber Attenuation 1260~1620nm
Product Overview
Customized MU/UPC 1260~1620nm Singlemode Fixed Fiber Optic Attenuator, Male-Female, 1~25dB Optional
Product Description
As optical passive devices, Gezhi Photonics attenuators are primarily used in fiber optic systems to debug optical power performance, calibrate optical instruments, and attenuate fiber signals to maintain optical power at stable and desired levels within the link without altering the original transmission wave.
Please note: E2000 is an LSH connector with a dust-proof cover.
Product Highlights
  • Applied for CWDM, DWDM, Test Equipment, CATV Systems, Point to Point Systems, etc.
  • Precision Polishing for Reduced Back Reflection
  • High Precision Fiber Optic Ceramic Ferrules
  • Standard Fixed Attenuation Values of 1dB up to 25dB
  • 1260 to 1620nm Wavelength Singlemode Attenuators
  • Attenuating Material - Ion Doped Fiber
  • Snap-in Body for Fast Mating and De-mating
Attenuator Features
Fixed Customized Singlemode Fiber Optic Attenuator with precise attenuation values, low PDL, low insertion loss and fine reflection polishing.
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Attenuator Applications
Optical attenuator is widely used in CWDM & DWDM systems, CATV systems, data center networks, test equipment and other high power applications.
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
Our Manufacturing Facility
Customized MU/UPC Single Mode Fiber Optic Attenuator with 1260~1620nm Wavelength and 1~25dB Attenuation Featuring Zirconia Ceramic Ferrule
