Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap
Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap
Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap
Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap
Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap
Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap
Specifications
MOQ :
1000 square meters
Key words :
galvanized welded pipeline steel mesh
Price :
USD 1.7-3 /square meter
Middle line wire pitch :
25.4 mm
Hardness range :
485N/mm² - 650N/mm²
Both sides line wire pitch :
25.4 mm or 50.8 mm
Surface treatment :
hot dipped galvanized
Certification :
ISO9001
Packaging Details :
steel strip six rolls each bundle
Cross wire pitch :
67 mm or 92.4 mm
Zinc coating :
up to50-60 g/m²
Mesh type :
Welded type
Supply Ability :
2000 Square meters per week
Wire diameter :
2.0mm, 2.2mm, 2.4mm, 2.7mm
Line wire quantity :
6, 8 or 10 lines
Roll width :
190.5 mm
Material :
Q235 low carbon steel wire / hot dipped galvanized
Product Name :
Galvanized Welded Pipeline Steel Mesh In Rolls For Subsea Oil And Gas Pipeline CWC
Model Number :
REINFORCE-138
Payment Terms :
T/T
Brand Name :
REINFORCE
Place of Origin :
China
Delivery Time :
14-20 working days
Roll length :
140 m / 280 m or customized
Description

Welded Low Carbon Steel Wire Pipeline Reinforcement Mesh Roll Underground Gas Pipeline Protection Wrap


Pipeline Reinforced Mesh


Pipeline Reinforced Mesh is one kind of our Welded mesh product.
It is also known as pipeline coating mesh which is widely used as reinforcement on concrete weight coating
pipelines for oil and gas.
It is designed to provide negative buoyancy and mechanical protection for pipelines in subsea and wet environments.


Pipeline Reinforced Mesh Normal Export Specifications:


Product name
Oil And Gas Pipeline Reinforcement Wire Mesh
Width
190.5mm
Mesh Hole Size
25.4/50.8mm x 67mm
Length per roll
140m, 280m
Hardness
485-650N/mm2
Wire Dia.
Mesh
Width
Length
2.0mm
25.4mm x 67mm
190.5mm
140m, 280m
2.2mm
25.4mm x 67mm
190.5mm
140m, 280m
2.4mm
25.4mm x 67mm
190.5mm
140m, 280m
2.6mm
25.4mm x 67mm
190.5mm
140m, 280m

Pipeline Reinforced Mesh Features:

1.Good material wire

2.Standard wire diameter

3.Uniform mesh hole size

3. Roll width and roll length both enough for every customer

4. Welded point strong
5. Strong tensile strength

6.High degree of flexibility

7.Anti-corrosion and anti-rust are strong
8.Exceptional continuity and uniformity

9.Use life long

10.Easy use

11.Suitable for store
12.Fast delivery time


Pipeline Reinforced Mesh Package:


usual packing tape to combine 6 small rolls into one large roll,which saves container space.


Pipeline Reinforced Mesh Applications:


Oil/Gas Pipelines: Subsea pipelines, swamp/lake crossings.

Hydraulic Engineering: Underwater pipeline counterweights and dam protection.

Industrial Facilities: Corrosion protection for sewage treatment plants and water pipelines.


Our Company Profile:


Hebei Reinforce Pipeline Mesh Co., Ltd is an enterprise focusing on deep-sea energy pipeline protection. It is located at No.6, Ruilian Industrial Zone B, Shuguang East Street, Xicheng Industrial Zone, Raoyang County, Hengshui City, Hebei Province. Our company takes the steel wire mesh for concrete weight coating of submarine oil and natural gas pipelines independently developed and produced as its core product. We also produce safety rope nets around platforms, steel gratings, and vibrating screens.
