Nested Structure Multi Stage Double Acting Telescopic Hydraulic Cylinders ID 160mm
Nested Structure Multi Stage Double Acting Telescopic Hydraulic Cylinders ID 160mm
Specifications
Brand Name :
EOOE Hydraulic
Model Number :
160/140/100/70-1327
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 PC
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
10000PCS/Year
Delivery Time :
2.5 month
Packaging Details :
Plastic Wrap+Wooden Box
QTY :
6 PCS
Condition :
New
Structure :
Nested Type
Pressure Testing :
100%
Warranty :
365 Days
Application Industry :
Dump Trucks
Sealing :
Parker
Painting :
According to Customer's Color
Description

Nested Structure Telescopic Hydraulic Cylinder with ID 160mm

Ⅰ. How Do Telescopic Hydraulic Cylinders work?

The telescopic cylinder is a kind of special cylinder. The diameter of the multi-stage cylinder block increases sequentially, forming a series from small to large. When hydraulic oil enters the hydraulic cylinder, the piston begins to move under pressure. In the first cylinder block, the piston has a smaller area, and due to the compressibility of the liquid, the pressure is higher. As the piston moves, liquid flows from the first cylinder into the second cylinder. Due to the larger area of the second cylinder, the pressure decreases, but as the area increases, the force also increases. By analogy, after the liquid flows through each cylinder block, the pressure decreases, but the force gradually increases.

Ⅱ. Parameters

Specification 160/140/100/70-1327
Type Double-Acting Cylinder
Advantage Enhanced Stability
Unique Design Designed to Provide Extended Stroke Lengths without Sacrificing Compactness
