SC840i Single Cylinder Hydraulic Cone Crusher with 421mm Feed Opening and 345mm Max Feed for Coarse Crushing
SC840i Single Cylinder Hydraulic Cone Crusher with 421mm Feed Opening and 345mm Max Feed for Coarse Crushing
SC840i Single Cylinder Hydraulic Cone Crusher with 421mm Feed Opening and 345mm Max Feed for Coarse Crushing
SC840i Single Cylinder Hydraulic Cone Crusher with 421mm Feed Opening and 345mm Max Feed for Coarse Crushing
SC840i Single Cylinder Hydraulic Cone Crusher with 421mm Feed Opening and 345mm Max Feed for Coarse Crushing
SC840i Single Cylinder Hydraulic Cone Crusher with 421mm Feed Opening and 345mm Max Feed for Coarse Crushing
Specifications
Min Discharge Opening :
25 mm
Supply Ability :
50 Sets / Month
Crushing Cavity Liner :
High manganese steel mantle and concave
Brand Name :
Peilan
Model Number :
SC840i
Place of Origin :
China
Packaging Details :
Main machine nude packing, spare parts packed in wooden cases; 1 set per 60HQ container
Overload Protection :
Single cylinder full hydraulic automatic system
Certification :
ISO 9001:2015
Price :
USD 60000 - 155000 / Unit
MOQ :
1 Unit
Delivery Time :
3-7 working days
Model :
SC840i
Payment Terms :
T/T
Lubrication System :
Thin oil circulation with cooling
Description

SC840i Single Cylinder Hydraulic Cone Crusher is a heavy-duty secondary and tertiary crushing machine engineered for large-scale mining and aggregate production lines. Equipped with extra-wide C1 and C2 coarse crushing cavities, the SC840i accepts feed sizes up to 345mm and delivers a minimum discharge opening of 25mm, making it an ideal primary-stage cone crusher for high-hardness ores.

An integrated single-cylinder hydraulic system provides one-key discharge opening adjustment and intelligent overload protection. When uncrushable materials enter the crushing chamber, the hydraulic cylinder automatically lowers the main shaft to widen the discharge gap and clear the obstruction, then restores the original setting automatically without manual intervention.

Technical Specifications
Model Cavity Type Feed Opening Size (mm) Max Feed Size (mm) Min Discharge Opening (mm)
SC840i C1 421 345 25
SC840i C2 345 275 32
Applications

Suitable for coarse and medium crushing of granite, basalt, iron ore, copper ore, limestone and river pebble in large mining plants, aggregate yards, highway and railway construction projects. Hourly capacity range covers 20-1126 t/h across the series.

Key Advantages
  • Extra-wide feed opening accepts large raw material directly, simplifying the upstream crushing stage
  • Single-cylinder full hydraulic system for one-key discharge adjustment and automatic overload protection
  • Laminated crushing action produces uniform cubic aggregates with fewer flaky particles
  • High-strength steel frame and anti-wear alloy liners support round-the-clock heavy-duty operation
  • Thin oil circulation lubrication with cooling keeps bearings running reliably in hot environments
