2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
Specifications
Brand Name :
SOOME
Model Number :
SMBD-ENC
Certification :
CE
Place of Origin :
Made in China
MOQ :
1 Set
Price :
Contact
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 Sets / month
Delivery Time :
60 Days
Packaging Details :
Wooden case or plastic film 1*20'' container
Wide size :
2000/2200/2500mm
Blade :
5/6/7
Scorer :
8/10/12
Min.scorer :
0mm
Usage :
Online cutting and creasing corrugated
Speed :
200/250m/min
Blade material :
Raw material, alloy tungsten steel
Precise :
±0.5mm
Description

2200Mm 7 Blade 200M/min Online Corrugated Thin Blade Slitter Scorer

Product overview:

As an important equipment of corrugated cadres,complete the high quality line of cardboard and precise cutting and the size is very precise.Adopt computer-controlled,automatic change order,and reduce waste,improve work efficiency.

width 1800mm 2200mm 2500mm
speed 150,200,250m/min
Blade&scorer 5&8,6&10,7&12
Order change

1s
precision ±0.5mm
Min.slitting 135mm
Min.scorer 0mm
Correction range

200mm
power

25kw

 30kw 35kw
machine size

3900*1800*2450(mm)

 4300*1800*2450(mm) 4500*1800*2450(mm)

Function and Characteristic:

1 . High quality touch screen and PLC equipped composing the CNC system,connect to the production line.

2 . High quality beeline rail guarantees the precision.

3 . A memory of orders,realize non-stop automatic or manual change.

4 . Speed synchronizes with board speed.Standard communication interface,easy to link with management system.

5 . Alloyed steel thin-blades,sharp and long life of over 8 million meters,auto sharpening

6 . The knife for computer control automatic or manual knife sharpening,edge trimming knife,improve production efficiency.

7 . Two types of scorers:convex to concave ,convex to flat.

8 . Two rows of scorers,realizes minimum scorer spacing is 0mm.

9 . Computer control score-depth,high quality scorer,more steady .

10 . Using the synchronous belt transmission ,low noise,prolong using time.

11 . Standard motorized body left-right rectification system 200mm

2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine2200mm 7 Blade Corrugated 200m/Min Slitter Scorer Machine
