Specifications
Brand Name :
SOOME
Model Number :
SMDM
Certification :
CE
Place of Origin :
China Hebei Dongguang
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30 set / 3 months
Delivery Time :
45 days
Packaging Details :
Wooden or plastic * 20”container or Shipping LCL
Corrugated roller :
Diameter Φ320
Roller material :
Alloy steel,or Tungsten carbide
Flute type :
ACBEF
Design Speed :
150m/min
Working Speed :
120m/min
Size :
1600/1800/2000/2200/2500
Usage :
Making corrugated cardboard
Changed roller time :
10 min
Description

Cassette Type Changed Fast Corrugated Production Line Single Facer

No. Name Qty Feature
1

Cassette Type Single Facer

 1

--Corrugated rollerφ320mm,48CrMo high quality alloy steel, tungsten carbide treatment

--Fast change the roller in 15 minus by electrical trailer

--Airbag ballast structure

--Independent glue unit with PLC control,circulating supply glue

--Man-machine interface display

--Automatic stopping machine and relief pressure without paper
Roller Fast Changed Model 1

--Fast change the corrugated roller for the cassette type single face

--The module part includes: two ends of the shaft seat,bearings,steam components,

suction box,pneumatic components and so on

Machine Description:

*Single facer is design for producing single-face corrugated paper:This machine is cassette type design, easy and quick to change flute in 15mins with dolly by hydraulic system

Machine Function:

*Corrugated Rollers:

Diameter

Φ320mm
Material 48CrMo high quality alloy steel, rigidity HRC55°-58°
Processing Way After quenching and tempering,The surface of upper-lower roller is ground, then tungsten carbide
Control Way Airbag control Lifting Up-down
Driving Way frequency motor
Way of Transmit cardboard Vacuum Cover absorbable style, Height pressure Draw fan with noise deadening device
Way of Bearing lubricating High temperature grease
Flute Type (U/V) ACBEF(According to customers requirements)

*Press Rollers:

Diameter

Φ370mm
Material Carbon steel (MS)45#
Processing Way After quenching and tempering,The surface of roller is ground, then plating chrome
Control Way Airbag control Lifting Up-down
Way of Bearing lubricating High temperature grease

*Glue Rollers:

Diameter

Φ269mm
Material Carbon steel (MS)45#
Processing Way Surface is ground,inscribed with 25 lines of pitted mesh,then plated chrome
Driving Way frequency motor
Way of Bearing lubricating High temperature grease
Glue Supply Automatic glue circulating system(storage tank+glue pump);PLC automatic control glue and electric adjust glue width；Independent glue unite

*Preheater Rollers:

Diameter Φ400mm
Material seamless steel tube
Processing Way After quenching and tempering,The surface of roller is ground, then plating chrome

Machine Technical Parameter:

Working Width 1800mm
Design Speed 150m/min
Working Speed 120m/min
Pneumatic Source Pressure(Mpa) 0.4---0.8Mpa
Main Drive Motor 30KW
Suction Motor 15KW
Glue Adjusting Reducer 0.1KW
Glue Gap Adjusting Motor 0.25KW
Glue Pump 2.2KW
