316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
Specifications
Outer Diameter :
12.7mm - 154mm
Supply Ability :
300 Metric Tons per Month
Standard :
ASTM A270, ASME BPE, 3A Sanitary
Packaging Details :
Plastic end caps on both ends, individually wrapped in cleanroom-grade polyethylene, packed in plywood cases
Wall Thickness :
1.0mm - 3mm (1.65mm standard)
Brand Name :
SYLAITH
MOQ :
100 Kilograms
Surface Finish :
Ra ≤ 0.8μm ID & OD (electropolished), Ra ≤ 0.5μm option
Tensile Strength :
≥ 485 MPa
Model Number :
SS316L-SAN-POL
Certification :
ISO 9001:2015, 3A Sanitary, ASME BPE
Length :
6m standard, custom available
Application :
Dairy Processing, Food & Beverage, Pharmaceutical, Biotechnology, Cosmetics
Place of Origin :
Jiangsu, China
Manufacturing Process :
Seamless or Welded, Cold Drawn
Price :
USD 5.5-12.0 / Kilogram
End Finish :
Square cut, deburred, plastic capped
Sulfur Content :
0.005% - 0.017% (controlled for weldability)
Delivery Time :
10-15 working days for stock, 15-25 days for production
Material Grade :
316L (UNS S31603, 1.4404)
Payment Terms :
T/T
Yield Strength :
≥ 170 MPa
Description
316L Stainless Steel Sanitary Tube - Food & Pharmaceutical Grade

SSM 316L sanitary stainless steel tubes are manufactured to the highest surface finish standards for hygienic processing. Both ID and OD polished to Ra ≤ 0.8μm (electropolished option down to Ra 0.5μm), these tubes meet 3A Sanitary and ASME BPE requirements.

316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade 316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
Key Features
  • Dual-Side Polished: Both internal and external surfaces polished to Ra ≤ 0.8μm, eliminating bacterial harborage points and ensuring cleanability
  • Electropolish Option: Available with electropolished ID finish (Ra ≤ 0.5μm) for critical pharmaceutical and biotechnology applications
  • 316L Low Carbon: Full austenitic structure with controlled sulfur content (0.005-0.017%) for optimal orbital welding performance
  • Cleanroom Packaging: Each tube end-capped and individually wrapped in cleanroom-grade polyethylene to prevent contamination during transit
Applications

Essential for dairy processing lines, brewery piping, pharmaceutical WFI (Water for Injection) systems, cosmetic manufacturing, food-grade heat exchangers, and biotechnology process piping.

316L Stainless Steel Sanitary Tube with Ra ≤ 0.8μm ID & OD Polished Finish for Food & Pharmaceutical Grade
Quality Assurance

Surface roughness profilometer tested, borescope inspected for internal defects, PMI chemistry verified, and hydrostatic pressure tested. Full material certification and surface finish reports provided.
