17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
Specifications
Brand Name :
Surmount
Model Number :
RGD2507
Certification :
CE
Place of Origin :
China
MOQ :
50PCS
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
600 pieces per day
Delivery Time :
5~8 working days
Packaging Details :
Carton
Size :
25x25x7mm
Frame Material :
Plastic
Impeller Material :
Plastic
Weight :
5g
Rated Voltage :
5V/12V
Noise :
20~31dBA
Rated Current :
0.06~0.21A
Rated Input Power :
0.72~1.08W
Speed :
7200~17000RPM
Bearing Type :
Sleeve
Air Flow :
1.22~2.84CFM
Lead Wire :
AWG#26 UL 1007(Optional)
Life Time :
40000 Hours
Mounting :
Free standing
Description

Mini DC Axial Cooling Fan 25x25x7mm 5V 12V Used On Small Appliances

What is a DC cooling fan?
DC fans also known as DC Brushless Fans are basically cooling fans engineered to meet requirements such as higher air flows at high static pressures. RENGANG manufactures Brushless DC fans in varied sizes ranging from 60 mm to 280 mm. These fans are available in the plastic blade as well as the metal blade.


What are axial fans used for?
In general, an axial-flow fan is suitable for a larger flow rate with a relatively small pressure gain and a centrifugal fan for a comparatively smaller flow rate and a large pressure rise. They are used to supply fresh air, suck air from return air trenches, suck air from rotary filters, exhaust air out, etc.

DC Axial Cooling Fan RGD2507

Energy Saving Noise Reduction Soft Wind Long Lasting

Basic Parameter:

Model No. Bearing Voltage Current Rated input power Airflow Air pressure Noise Speed
(V) (A) (W) (CFM) (m3/min) (inch-H2O) (mm-H2O) (dBA) (RPM)
RGD2507D5S Sleeve 5 0.21 1.05 2.84 0.08 1.77 4.50 31 17000
RGD2507H5S 0.18 0.90 1.90 0.05 1.15 3.80 26 14000
RGD2507M5S 0.16 0.80 1.55 0.04 1.22 3.10 24 10000
RGD2507L5S 0.13 0.65 1.22 0.03 0.09 2.16 20 7200
RGD2507D12S 12 0.09 1.08

2.84

 0.08 1.77 4.50 31 17000
RGD2507H12S 0.08 0.96 1.90 0.05 1.15 3.80 26 14000
RGD2507M12S 0.07 0.84 1.55 0.04 1.22 3.10 24 10000
RGD2507L12S 0.06 0.72 1.22 0.03 0.09 2.16 20 7200

Applicable: Small Appliances, Laptop

Customized Support: OEM, ODM.

After-sales Service Provided: Free Spare Parts

Drawing:

17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances

Characteristic Curve:

17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances

Parts:

17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances

Payment:

1.Trade Assurance: In the first order, we suggest you use Trade Assurance.

2.T/T: If stocks,100% payment before shipping; if customized order, 30% deposit before production and balance 70% should be paid before delivery.

3.Western Union, Money Gram, Paypal, all available.

4.L/C: for large order.
17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances

Shipping:

1.ln general, we use international express, DHL, UPS,FedEx,EMS,TNT, etc.Large order: by air or sea, you should choose it.

2. if you have your own forwarder, please tell us the detailed information.

17000RPM 25x25x7mm DC Axial Cooling Fan 12V On Small Appliances
