Specifications
Connector Type :
接头
Frequency :
4GHz
Impedance :
50Ω
Description :
Connector 4GHz 50Ω Coaxial Connector (RF) Adapters RoHS
Mfr. Part # :
79025
Model Number :
79025
Description

Product Overview

Amphenol Corporation offers a range of straight adapters designed for connecting between different series of RF connectors. These adapters facilitate seamless transitions between common coaxial connector types such as BNC, N, SMA, TNC, and UHF. They are suitable for various applications requiring reliable signal transmission.

Product Attributes

  • Brand: Amphenol
  • Product Type: Straight Adapters, Between Series

Technical Specifications

Amphenol Number Adapter Ends Military Number VSWR (max.) Frequency (DC-GHz) Length (in/mm) Diameter (in/mm) Figure
5225 BNC Plug to N Plug UG-1034/U 1.35 DC-4 1.50 (38.1) .812 (20.6) across 2 flats Fig. 1
31-217 BNC Plug to N Jack UG-349A/U 1.35 DC-4 1.56 (39.7) .625 (15.9) across 2 flats Fig. 2
31-217RFX BNC Plug to N Jack - 1.35 DC-4 1.56 (39.7) .625 (15.9) across 2 flats Fig. 2
901-164 BNC Plug to SMA Plug - 1.3 DC-4 1.09 (27.8) .562 (14.3) dia. Fig. 3
901-165 BNC Plug to SMA Jack - 1.3 DC-4 1.06 (27.0) .562 (14.3) dia. Fig. 4
79025 BNC Plug to TNC Jack - 1.25 DC-4 1.25 (31.8) .625 (15.9) across 2 flats Fig. 5
2900 BNC Plug to UHF Jack UG-255/U - DC-4 1.31 (33.3) .625 (15.9) across 2 flats Fig. 6
