PC board assembly solutions with Keystone 1280 quick fit headers providing strong terminal retention
PC board assembly solutions with Keystone 1280 quick fit headers providing strong terminal retention
Specifications
Description :
Quick Connects, Quick Disconnect Connectors RoHS
Mfr. Part # :
1280
Model Number :
1280
Description

Product Overview

.250 (6.4) STURDI-MOUNT PC QUICK-FIT HEADERS QUICK-FIT TERMINALS are designed for rugged multi-insertion applications, offering pre-assembled headers to reduce PC assembly costs and increase PC board retention strength. They maintain terminal perpendicularity and position for wave soldering.

Product Attributes

  • Brand: KEYELCO
  • Certifications: UL recognized, ISO 9001 CERTIFIED, RoHS COMPLIANT
  • Material Options: Bright Brass, Steel (Tin Plated)
  • Color: Bright Brass, Matte Tin
  • Origin: USA (Astoria, NY)

Technical Specifications

Product TypeCatalog NumberMaterialTab SizeTab ThicknessTab WidthHole DiameterLength (L)Angle (A)Number of TabsDimensions (Dim.)
STURDI-MOUNT PC QUICK-FIT HEADERS4005Brass or Steel, Tin Plated.132 (3.4) x .070 (1.78) Slot-------
STURDI-MOUNT PC QUICK-FIT HEADERS4095Brass or Steel, Tin Plated.187 (4.7) Dia. Hole-------
QUICK-FIT TERMINALS (Rivet Mount)1269Bright Brass.110 (2.8) to .250 (6.4).020 (.51).180 (4.6).096 (2.4)-0--
QUICK-FIT TERMINALS (Rivet Mount)1270Bright Brass.110 (2.8) to .250 (6.4).020 (.51).180 (4.6).096 (2.4)-30--
QUICK-FIT TERMINALS (Rivet Mount)1240Bright Brass.110 (2.8).020 (.51).283 (7.2).180 (4.6).096 (2.4)45--
QUICK-FIT TERMINALS (Rivet Mount)1227Bright Brass.110 (2.8).020 (.51).283 (7.2).180 (4.6).096 (2.4)90--
QUICK-FIT TERMINALS (Rivet Mount)1263Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-45--
QUICK-FIT TERMINALS (Rivet Mount)1262Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-90--
QUICK-FIT TERMINALS (Rivet Mount)1241Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-45--
QUICK-FIT TERMINALS (Rivet Mount)1228Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-90--
QUICK-FIT TERMINALS (Rivet Mount)1258Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-45--
QUICK-FIT TERMINALS (Rivet Mount)1257Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-90--
QUICK-FIT TERMINALS (Rivet Mount)1242Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-45--
QUICK-FIT TERMINALS (Rivet Mount)1229Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-90--
QUICK-FIT TERMINALS (Rivet Mount)2005Bright Brass.110 (2.8).020 (.51).283 (7.2).180 (4.6).096 (2.4)45--
QUICK-FIT TERMINALS (Rivet Mount)2003Bright Brass.110 (2.8).020 (.51).283 (7.2).180 (4.6).096 (2.4)90--
QUICK-FIT TERMINALS (Rivet Mount)1233Bright Brass.110 (2.8).020 (.51).283 (7.2).180 (4.6).096 (2.4)45--
QUICK-FIT TERMINALS (Rivet Mount)1220Bright Brass.110 (2.8).020 (.51).283 (7.2).180 (4.6).096 (2.4)90--
QUICK-FIT TERMINALS (Rivet Mount)1271Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-45--
QUICK-FIT TERMINALS (Rivet Mount)1261Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-90--
QUICK-FIT TERMINALS (Rivet Mount)1234Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-45--
QUICK-FIT TERMINALS (Rivet Mount)1221Bright Brass.187 (4.8).020 (.51).250 (6.4).100 (2.5)-90--
QUICK-FIT TERMINALS (Rivet Mount)1280Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-45--
QUICK-FIT TERMINALS (Rivet Mount)1256Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-90--
QUICK-FIT TERMINALS (Rivet Mount)1235Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-45--
QUICK-FIT TERMINALS (Rivet Mount)1222Bright Brass.250 (6.4).032 (.81).312 (7.9).130 (3.3)-90--
MULTIPLE TAB HEADERS (Brass)7802Brass----.362 (8.2)-2-
MULTIPLE TAB HEADERS (Steel)7822Steel----.362 (8.2)-2-
MULTIPLE TAB HEADERS (Brass)7803Brass----.562 (14.3)-3-
MULTIPLE TAB HEADERS (Steel)7823Steel----.562 (14.3)-3-
MULTIPLE TAB HEADERS (Brass)7804Brass----.762 (19.4)-4-
MULTIPLE TAB HEADERS (Steel)7824Steel----.762 (19.4)-4-
MULTIPLE TAB HEADERS (Brass)7805Brass----.962 (24.4)-5-
MULTIPLE TAB HEADERS (Steel)7825Steel----.962 (24.4)-5-
MULTIPLE TAB HEADERS (Brass)7806Brass----1.162 (29.5)-6-
MULTIPLE TAB HEADERS (Steel)7826Steel----1.162 (29.5)-6-
MULTIPLE TAB HEADERS (Brass)7817Brass----.320 (8.1)-2-
MULTIPLE TAB HEADERS (Steel)7827Steel----.320 (8.1)-2-
MULTIPLE TAB HEADERS (Brass)7818Brass----.517 (13.1)-3-
MULTIPLE TAB HEADERS (Steel)7828Steel----.517 (13.1)-3-
MULTIPLE TAB HEADERS (Brass)7819Brass----.713 (18.1)-4-
MULTIPLE TAB HEADERS (Steel)7829Steel----.713 (18.1)-4-
MULTIPLE TAB HEADERS (Brass)7820Brass----.910 (23.1)-5-
MULTIPLE TAB HEADERS (Steel)7830Steel----.910 (23.1)-5-
MULTIPLE TAB HEADERS (Brass)7821Brass----1.107 (28.1)-6-
MULTIPLE TAB HEADERS (Steel)7831Steel----1.107 (28.1)-6-
QUICK-FIT TERMINALS (2-Tab Pairs)1005Brass, Tin Plate-.020 (.51)--.687 (17.4)-2-
QUICK-FIT TERMINALS (3-Tab Pairs)1006Brass, Tin Plate-.020 (.51)--1.062 (27.0)-3-
QUICK-FIT TERMINALS (4-Tab Pairs)1007Brass, Tin Plate-.020 (.51)--1.441 (36.6)-4-
QUICK-FIT TERMINALS (5-Tab Pairs)1008Brass, Tin Plate-.020 (.51)--1.820 (46.2)-5-
Specifications-Insulator: Thermoplastic, UL Rated 94V-0Current Rating: 15 Amps @ 500V ACTemperature Rating: -58F to +292F (-50C to +145C)------

2410121538_Keystone-1280_C5370869.pdf
