Specifications
Description :
Heavy Duty Connector Contacts RoHS
Mfr. Part # :
VN0101600242C
Model Number :
VN0101600242C
Description

Product Overview

The Amphenol heavy|mate is a modular heavy-duty connector line designed for harsh industrial environments. It offers robust design, high pole counts, excellent EMC protection, and secure locking systems for reliable power, signal, and data transmission. The system is modular, allowing for customized solutions and is compatible with market standards.

Product Attributes

  • Brand: heavy|mate
  • Manufacturer: Amphenol
  • Origin: Amphenol Tuchel Industrial GmbH
  • Certifications: VDE, UL, CSA approvals
  • Material: Metal (Housings), PA (Modules, Protective Cover), CuZn (Contacts), CuSn (Socket Contacts for D series), PC (Inserts), Aluminium die cast alloy (Metal Housings), CR (Rubber Gasket for IP67), NBR (Rubber Gasket for IP65), Silicon (Rubber Gasket for IP68/IP69K), Cu-alloy (Metal Housing A3/4), Cu alloy (Shielding for F series), Zinc alloy (Shielding for F series)
  • IP Rating: IP65, IP67, IP68, IP69K
  • Corrosion Resistance: Yes
  • Vibration Proof: Yes
  • EMC Protection: Very good

Technical Specifications

Series Rated Voltage Rated Current Number of Contacts Termination IP Rating Contact Plating
heavy|mate A 250 / 400 V 10 A / 16 A 3, 4, 10, 16, 32 Screw IP00 (unmated pin), IP20 (mated pin) Ag (silver)
heavy|mate D 250 V 10 A / 16 A 7, 8, 15, 25, 40, 50, 64, 128 Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate DD 250 V 10 A 24, 42, 72, 108 Crimp, PCB IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate E 500 V 16 A 6, 10, 16, 24, 48 Screw, Crimp, Tension spring, Push-in IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate EE 500 V 16 A 10, 18, 32, 46 Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate EEE 500 V 16 A 40, 64 Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate E / FE / KO 500 V 10 A 6, 10, 16, 24 Screw IP00 (unmated pin), IP20 (mated pin) Gal Cd (iron), without plating (constantan)
heavy|mate F Up to 1000 V Up to 220 A 1 - 108 Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver)
heavy|mate K Up to 830 V Up to 80 A 4, 4+2+, 6+36+ Screw, Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver)
heavy|mate M 63 - 1000 V 5 A ... 220 A 1, 2, 3, 4, 5, 10, 20 Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate Q Up to 690 V Up to 40 A 5, 4+2+, 7, 8, 12, 17 Crimp IP00 (unmated pin), IP20 (mated pin) Ag (silver) / Au (gold)
heavy|mate HSE 400 V 42 A 6 Screw IP00 (unmated pin), IP20 (mated pin) Ag (silver)
heavy|mate HvE 660 V 16 A 3, 6, 10, 16, 32 Screw IP00 (unmated pin), IP20 (mated pin) Ag (silver)

2411041531_Amphenol-VN0101600242C_C17371966.pdf
