Specifications
Description :
Heavy Duty Connector Contacts RoHS
Mfr. Part # :
VN0101001312
Model Number :
VN0101001312
Description

Product Overview

The Amphenol heavy|mate is a modular heavy-duty connector line designed for harsh industrial environments. It offers robust design, high pole counts, excellent EMC protection, and secure locking systems for reliable power, signal, and data transmission. With a wide range of series, voltage ratings up to 1000V, and IP ratings from IP65 to IP69K, heavy|mate connectors provide corrosion resistance and vibration-proof performance, making them suitable for demanding industrial applications.

Product Attributes

  • Brand: heavy|mate
  • Manufacturer: Amphenol Tuchel Industrial GmbH
  • Origin: Germany
  • Certifications: VDE, UL, CSA approvals
  • Material (Contacts): CuZn (brass), CuSn (tin bronze)
  • Contact Plating: Silver (Ag), Gold (Au)
  • Material (Inserts/Modules): PA, PC, PBT
  • IP Ratings: IP65, IP67, IP68, IP69K
  • Locking System: Robust metal levers, Key pin, Locking devices
  • EMC Protection: High
  • Corrosion Resistance: Yes
  • Vibration Proof: Yes
  • Flame Retardancy: UL 94 V-0
  • Railway Fire Safety: HL3 acc. EN 45545: R22/23

Technical Specifications

Series Rated Voltage Rated Current Number of Contacts Termination Technique Wire Gauge Max. Wire Diameter IP Degree of Protection (Mated)
A 250 / 400 V 10 A ... 16 A 3, 4, 10, 16, 32 Screw 0.5 - 1.5 mm (AWG 20 - 16) 3.6 mm / 4.6 mm IP20
D 250 V 10 A ... 16 A 7, 8, 15, 25, 40, 50, 64, 128 Crimp 0.14 mm - 2.5 mm (AWG 26 - 14) 4.1 mm IP20
DD 250 V 10 A 24, 42, 72, 108 Crimp, PCB 0.14 mm - 2.5 mm (AWG 26 - 14) 3.7 mm IP20
E 500 V 16 A 6, 10, 16, 24, 48 Screw, Crimp, Tension Spring, Push-in 0.14 - 4 mm / Push-in 0.14 - 2.5 mm 4.6 mm IP20
EE 500 V 16 A 10, 18, 32, 46 Crimp 0.14 mm - 4.0 mm (AWG 26 - 12) 4.8 mm IP20
EEE 500 V 16 A 40, 64 Crimp 0.14 mm - 4.0 mm (AWG 26 - 12) 4.6 mm IP20
E / FE / KO 500 V 10 A 6, 10, 16, 24 Screw 0.5 mm - 2.5 mm (AWG 20 - 14) 4.6 mm IP20
F Up to 1000 V Up to 220 A 1 - 108 (Modular) Crimp 25 - 95 mm (AWG 4 - 000) for 1 contact module; 10 - 35 mm (AWG 8-2) for 2 contact module 20 mm (1 contact); 12.8 mm (2 contacts) IP20
HSE 400 V 42 A 6 Screw 0.5 - 6.0 mm (AWG 20 - 10) 6.4 mm IP20
HvE Up to 660 V 16 A 3, 6, 10, 16, 32 Screw 0.5 - 2.5 mm 4.6 mm IP20
K Up to 830 V Up to 80 A 4, 4+2+, 6+36+, 4+8+ Screw, Crimp Power: 1.5 - 16 mm; Signal: 0.14 - 2.5 mm Power: 11 mm, Signal: 4.8 mm IP20
M Up to 1000 V Up to 220 A Various (Modular) Crimp 0.09 - 95 mm Up to 20 mm IP20
Q Up to 690 V Up to 40 A 5, 4+2+, 7, 8, 12, 17 Crimp Power: 1.5 - 6 mm; Signal: 0.14 - 2.5 mm Power: 5.2 mm, Signal: 3.7 mm IP20
