3M 234-3034-01-0602
3M 234-3034-01-0602
3M 234-3034-01-0602
3M 234-3034-01-0602
Specifications
MOQ :
10
Delivery Time :
15-21周
Model Number :
234-3034-01-0602
Packaging Details :
Through Hole
Number of Positions :
34P
Stock :
10000
Brand Name :
234-3034-01-0602
Description :
34P Through Hole IC Sockets RoHS
Description

Product Overview

The 3M Textool Axial Lead ZIP Strip Sockets are designed for devices with .050 (1.27 mm) lead centers, accommodating unformed or axially extending leads. These sockets feature a lever-actuated zero insertion force mechanism and a socket without a top-plate cover, enabling horizontal insertion of leads. They are frequently used in pairs to handle non-standard Flat Packs with leads on .050 (1.27 mm) centers. Left and right-hand versions must be ordered separately to form a complete pair. These sockets accept pins up to 0.14 (0.36 mm) to 0.25 (0.64 mm) square.

Product Attributes

  • Brand: 3M Textool
  • Insulation Material: Glass Filled Polysulfone
  • Insulation Flammability: UL 94V-0
  • Insulation Color: Green
  • Contact Material: Beryllium Copper
  • Contact Plating: 30 (0.76 m) Gold over 50 (1.3 m) Nickel
  • Marking: 3M Logo & Part Number Identifier
  • Origin: Printed in USA

Technical Specifications

Specification Value
Lead Center Spacing .050 (1.27 mm) x .100 (2.54 mm)
Pin Diameter Acceptance Up to 0.14 (0.36 mm) to 0.25 (0.64 mm) square
Current Rating 1 Amp
Insulation Resistance > 1 109 W at 500 Vdc
Withstanding Voltage 1000 Vrms at Sea Level
Operating Temperature Rating -55C to +125C
Contact Tail Length .19 [ 4.9 ]
Mounting Screws 2X #0-80
Contact Pattern -01, -02
Dimensions (34 Contacts) A: 2.65 [ 67.3 ] in (mm), B: 1.650 [ 41.91 ] in (mm), C: 2.46 [ 62.5 ] in (mm)
Dimensions (35 Contacts) A: 2.65 [ 67.3 ] in (mm), B: 1.700 [ 43.18 ] in (mm), C: 2.46 [ 62.5 ] in (mm)
Dimensions (36 Contacts) A: 3.45 [ 87.6 ] in (mm), B: 2.500 [ 63.50 ] in (mm), C: 3.27 [ 83.1 ] in (mm)
Socket Part Number (34 Contacts, -01 Pattern) 234-3034-01-0602
Socket Part Number (35 Contacts, -01 Pattern) 235-3019-01-0602
Socket Part Number (51 Contacts, -01 Pattern) 251-5949-01-0602
Socket Part Number (34 Contacts, -02 Pattern) 234-3034-02-0602
Socket Part Number (35 Contacts, -02 Pattern) 235-3019-02-0602
Socket Part Number (51 Contacts, -02 Pattern) 251-5949-02-0602
Tolerance (Dimension) .010 ( .25) inch (mm)
Tolerance (Dimension) .005 ( .13) inch (mm)
