SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
Specifications
Brand Name :
SIPU
Model Number :
SMA-KB2-068PE-50
Certification :
ISO9001, R0HS, CE
Place of Origin :
China
MOQ :
50
Price :
Provide a quotation
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
100000pcs/year
Delivery Time :
6-8work days
Packaging Details :
master carton
Product name :
SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
Characteristic impedance :
50Ω
Frequency range :
DC-18GHz
Description

SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable

Product Overview

This RF coaxial cable assembly utilizes an 086PE semi-flexible cable, constructed with three essential layers: an inner conductor (signal transmission), an insulating layer (signal isolation), and an outer conductor (shielding and protection). This layered structure ensures optimal signal integrity by minimizing external interference and signal leakage.

Cable Flexibility Categories:

Semi-steel cables – Rigid, formable

Semi-flexible cables – Moderate bendability with stable phase

Flexible cables – Lightweight and highly bendable

Product Features:

Connector Type: One end terminated with SMA-KB2, the other end left stripped (customizable length) for flexible integration.

Cable Type: 086PE semi-flexible coaxial cable

Performance: Low insertion loss, wide bandwidth, and excellent electrical uniformity

Customizable: Stripped end can be tailored for specific applications or connector assemblies

Mechanical Flexibility: Shape-adjustable within a certain range

Application Fields:

Military electronics

Aerospace systems

Mobile communication infrastructure

RFID systems

Communication terminals

RF test and measurement equipment

Product Specifications and Testing Indicators

SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable

Important Technical Parameters

Electrical property

Temperature range

 -55～+125℃

Characteristic impedance

 50Ω

Frequency range

 DC-18GHz

Dielectric withstanding voltage

 1000V

VSWR

 ≤1.3

Insulation resistance

 ≥5000MΩ

Insertion loss

 ≤0.5dB

Phase equalization

 /

Insertion loss consistency

 ≤±0.1dB

Product Image Gallery

SMA Female RF Cable Assembly with Single-Ended 086PE Coaxial CableSMA Female RF Cable Assembly with Single-Ended 086PE Coaxial CableSMA Female RF Cable Assembly with Single-Ended 086PE Coaxial Cable
