Reliable Gigabit Ethernet Slip Ring IP51 Protection Aluminum Alloy Housing
Reliable Gigabit Ethernet Slip Ring IP51 Protection Aluminum Alloy Housing
Specifications
Brand Name :
GuRen
Model Number :
GK2586-56P-1
Certification :
ISO9001.CE.RoHS
Place of Origin :
china
MOQ :
1
Price :
＄19-199
Payment Terms :
L/C,D/P,T/T
Supply Ability :
1K units/week
Delivery Time :
3 weeks ARO
Packaging Details :
Standard/On Request
Rotation speed :
250rpm
Shell material :
Aluminum Alloy
Protection level :
IP51
Network Channel :
2 group (including 18 channels)
Network bandwidth :
1000M
Wire length :
200cm
Description

GK2586-56P-1 Gigabit network signal slip ring integrates 10 current channels, 28 signal channels and 2 sets of Gigabit Ethernet channels to help realize the rotational transmission of product current, signal and network.


GK2586-56P-1 Gigabit network signal slip ring connector Features

1. The product features an RJ45 connector for convenient network connection.
2. 56 total channels for power and signal transmission.
3. Aluminum alloy housing with an IP51 protection rating.
4. Precious metal contact materials guarantee a service life of up to 20 million cycles.


GK2586-56P-1 Gigabit network signal slip ring connector Parameters

Ethernet

2 (1000M)

Connector Type

RJ45 male connector at both ends (female connector optional)

Mechanical Specifications

Electrical Specifications

Parameter

Numeric

Parameter

Parameter

power

Signal

Speed

250rpm

Voltage

440V AC/VDC

440V AC/VDC

Working life

2 million rpm

Insulation resistance

≥1000MΩ/500VDC

≥1000MΩ/500VDC

Operating humidity

0～85%RH

Wire Specifications

AWG#17andAWG#22

tinned Teflon wire

AWG#26tinned Teflon wire

Operating temperature

-30'C-80C

Dielectric strength

500VAC@50Hz,60S

Contact material

Precious Metals

Dynamic resistance change value

<0.01Ω

Shell material

Aluminum Alloy

Wire length

Standard length 300mm

Rotation torque

0.01N.m+0.03N.m/6 channels

Electrical noise

<10 milliohms

Shockproof level

MIL-STD-810E


GK2586-56P-1 Gigabit network signal slip ring Application Scenario

Ethernet slip rings are widely used in industries such as Industry 4.0 and automation (smart factories, logistics sorting, CNC machining), security and intelligent monitoring (panoramic monitoring systems, border patrol equipment), energy and infrastructure (wind turbines, solar power stations, hydropower station gates), medical and scientific research equipment, etc.
