25mm OD Gigabit Ethernet Hybrid Slip Ring Flange Mount 26 Channel
25mm OD Gigabit Ethernet Hybrid Slip Ring Flange Mount 26 Channel
Specifications
Brand Name :
GuRen
Model Number :
WX25-56P
Certification :
ISO9001.CE.RoHS
Place of Origin :
china
MOQ :
1
Price :
＄19-199
Payment Terms :
L/C,D/P,T/T
Supply Ability :
1K units/week
Delivery Time :
3 weeks ARO
Packaging Details :
Standard/On Request
Rotation speed :
200rpm
Shell material :
Aluminum Alloy
Protection level :
IP41
Network Channel :
2 group (including 18 channels) Shielded
Network bandwidth :
Gigabit Ethernet
Wire length :
250mm
Description

WX25-56P Gigabit Ethernet hybrid slip ring is specially designed for the transmission of network and current through rotation, and is used in automation equipment and small precision electronic equipment.


WX25-56P Gigabit Ethernet hybrid slip ring Features

1. The product features an aluminum alloy housing with a commonly used 25mm outer diameter, making it easy to replace and install.
2. It integrates two shielded Gigabit Ethernet ports, six 5A circuits, and 20 2A circuits.
3. It has an IP41 protection rating and a rotation speed of 200 rpm.
4. Internal gold-gold contacts and high-quality Teflon cable ensure stable transmission.


WX25-56P Gigabit Ethernet hybrid slip ring Parameters

Ethernet

2 (1000M )

Connector Type

RJ45 male connector at both ends (female connector optional)

Mechanical Specifications

Electrical Specifications

Parameter

Numeric

Parameter

Parameter

power

Signal

Speed

200rpm

Voltage

220V AC/VDC

220V AC/VDC

Working life

6 million rpm

Insulation resistance

≥500MΩ/300VDC

≥500MΩ/300VDC

Operating humidity

0～85%RH

Wire Specifications

AWG#28 tinned Teflon wire

CAT5E network cable

Operating temperature

-30'C-80C

Dielectric strength

300VAC@50Hz,60S

Contact material

Gold-Gold

Dynamic resistance change value

<0.01Ω

Shell material

Aluminum Alloy

Wire length

Standard length 250mm

Rotation torque

0.01N.m+0.03N.m/6 channels

Electrical noise

<10 milliohms


WX25-56P Gigabit Ethernet hybrid slip ring Application Scenario

Ethernet slip rings are widely used in industries such as Industry 4.0 and automation (smart factories, logistics sorting, CNC machining), security and intelligent monitoring (panoramic monitoring systems, border patrol equipment), energy and infrastructure (wind turbines, solar power stations, hydropower station gates), medical and scientific research equipment, etc.
