Wide Range Cold Climate Heat Pump Systems , Air Water Heat Pump 2HP
Wide Range Cold Climate Heat Pump Systems , Air Water Heat Pump 2HP
Specifications
Brand Name :
Yushen
Model Number :
SLNA-009U(P) SLNA-007UVP , SLNA(B)-014UP
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Cold Climate Heat Pump Systems
Compressor capacity :
2HP
Feature :
Wide Range
Water pipe diameter :
G1〞
Suitable working conditions :
-25C~+45C
Electricity :
220V-3N-50hz
Description

Wide Range Cold Climate Heat Pump Systems , Air Water Heat Pump 2HP

Cold Climate Heat Pump Systems Introduction

  1. Air source heat pump The cold (hot) water unit adopts modular design. It does not need to set up a standby unit. During the operation, the computer automatically controls and adjusts the running status of the unit to make the output power adapt to the working environment.
  2. The performance of air source heat pumps will vary with outdoor climate changes.
  3. In places where the outdoor air temperature in the north of China is low, an auxiliary heater is required due to insufficient heat supply in the winter of the heat pump.

Cold Climate Heat Pump Systems Features

It adopts Copeland compressor and operates in an ultra-wide range.
◆The reverse flow circuit is arranged to ensure the subcooling degree of the refrigerant, which effectively improves the heating efficiency and the normal operation of the unit at low temperature.
◆ It operates under ultra-low temperature conditions and can work normally at -25 °C.
◆ Energy efficiency guarantee, solve the common problem of low temperature, no heat, low energy efficiency.

Air Source Heat Pump Underfloor Heating Parameters

code name.pdf

Model SLNA-007UM
Compressor capacity 2HP
Function Heating and Cooling
Electricity 220V-1N-50Hz
Working conditions ℃ -25~～+45
Data Heata Nominal capacity KW 3.9
Input power KW 1.69
COP / 2.3
Heating IPLV(H) 2.53
Coolb Nominal capacity KW 4.4
Input power KW 1.69
COP / 2.6
Cooling IPLV(C) 2.7
A7W35c KW/COP 6.4/4.1
A2W35 KW/COP 5.8/3.6
A-7W35 KW/COP 4.3/2.7
A-15W55 KW/COP 3.4/1.9
A-20W45 KW/COP 2.9/1.94
Max. running currency A 13.2
Compressor quantity set 1
Refrigerant/charging quantity kg / R404A/2.2
Air blow type / Side
Water pipe diameter inch G1〞
Rating flow m³/h 1.6
Water side pressure loss kPa ≤35
Noise level dB(A) 59
Overall dimensions(L×W×H) mm 1087×435×901
Weight kg 70

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃
