NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
Specifications
Brand Name :
Nvidia
Model Number :
CX6 MCX623106AN-CDAT
Certification :
ROHS/ISO9001/CE
Place of Origin :
China
MOQ :
1 PC
Price :
USD 1120 PCE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
15 workdays
Technology :
Ethernet
Port :
Dual-Port QSFP56
Supported Ethernet Speeds :
100/50/40/25/10/1GbE
Link Rate :
16.0 GT/s
Controller :
Mellanox Technologies MT28800 Family ConnectX-5
Cabling Type :
QSFP28 Transceiver, DAC and AOC
Size (Low Profile) :
142.00mm x 68.90mm
Operating Temperature :
0 to 55 °C (32 to 131 °F)
Storage Temperature :
-40 to 70 °C (-40 to 158 °F)
Description

ConnectX-6 Dx SmartNIC MCX623106AN-CDAT is the industry's most secure and advanced cloud network interface card to accelerate mission-critical data-center applications, such as security, virtualization, SDN/NFV, big data, machine learning, and storage. The 100 Gigabit Ethernet adapter card provides up to two ports of 100 Gb/s Ethernet connectivity and delivers the highest return on investment (ROI) of any smart network interface card.

Feature:

* 1/10/25/40/50/100 Gb/s Ethernet, PAM4/NRZ
* Various form factors:
* PCIe low-profileOCP 3.0 Small Form Factor (SFF)OCP 2.0
* Connectivity options:
* SFP28, SFP56, QSFP28, QSFP56
* PCIe Gen 3.0/4.0 x16 host interface
* Multi-host and single-host flavors
* Crypto and non-crypto versions

Specificiation:

Part Number
MCX623106AN-CDAT
Product Other Code
900-9X6AG-0056-ST1
Size:
5.59in. x 2.71in (142.00mm x 68.90mm)
Connector:
Dual QSFP56 Ethernet (copper and optical)
Data Rate
1/10/25/40/50/100 Gb/s
Interface form factor
PCI Express Gen 3.0/4.0
Voltage:
3.3Aux
Maximum current:
100mA
Temperature
Operational 0°C to 55°C
Non-operational -40°C to 70°C
Humidity
Operational 10% to 85% relative humidity
Non-operational 10% to 90% relative humidity
Safety Regulatory
CB / cTUVus / CE
EMC Regulatory
CE / FCC / VCCI / ICES / RCM
RoHS
RoHS compliant

Application:

NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56

Testing:

Advanced Networking and Security
It supports SR-IOV and VirtIO hardware virtualization, optimizing performance, offloading cloud networking workloads, freeing CPU cores, and reducing total cost of ownership.

NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56

Unlock Seamless Network Performance with Compatibility Testing
Through comprehensive testing procedures, we ensure seamless compatibility with mainstream servers, guaranteeing the long-term reliability and stability of the entire network infrastructure.

NVIDIA Mellanox MCX623106AN-CDAT ConnectX-6 Dx EN Network Interface Card, 100GbE Dual-Port QSFP56
