25G Ethernet SFP Optical Module DDM With 1310nm DFB Transmitter
25G Ethernet SFP Optical Module DDM With 1310nm DFB Transmitter
Specifications
Brand Name :
coloroptic
Model Number :
C-S82585SC
Certification :
UL, TUV, CE, RoHS, REACH, CMRT
Place of Origin :
China
MOQ :
2
Price :
Negotiable
Payment Terms :
TT, LC, Western Union
Supply Ability :
1000 pieces/month
Delivery Time :
7~15 days
Packaging Details :
Plates with Carton
Data rate :
25G
Wavelength :
1310nm
Distance :
300m on OM3 MMF
Connector :
MPO
Form Factor :
SFP28
Temperature :
-40 to 85°C
DDM :
Yes
Protocals :
MSA
Warranty :
3 years
Label :
Can Be Customized
Protocols: :
SFP8472
Application :
Wireless base station system
Description

25G Ethernet SFP Optical Module with 1310nm DFB Transmitter, -40~85°C

This 25G SR optical transceivers are based on 25G Ethernet IEEE 802.3 standard. They are compliant with FC-PI-6,SFF-8402,SFF-8419,SFF-8432 and SFF-8472, providing a fast and reliable interface for 25G Ethernet applications. The product implements the digital diagnostics required by the SFF-8472 via a 2-wire serial bus.

Key Features
  • Supports CPRI and Ethernet application
  • 1310nm DFB transmitter
  • PIN photo-detector
  • 2-wire interface for management specifications compliant with SFF-8472 digital diagnostic monitoring interface for optical transceivers
  • Operating case temperature:-40 to 85°C
  • All-metal housing for superior EMI performance
  • 25G electrical interface (OIFCEI-28G-VSR)
  • Maximum power consumption 1.2W
  • Advanced firmware allow customer system encryption information to be stored intransceiver
  • RoHS compliant
Application
  • ·High-speed storage area networks
  • Computer cluster cross-connect
  • Custom high-speeddata pipes
  • Wireless base station system
Product Details

Parameter Symbol Min Typical Max Units No
Operating Case Temperature TOP -40 　 85 degC 　
Link Distance with OM3 D 0.002 　 300 m 　
Power Consumption 　 　 　 1.2 W 　
Center Wavelength λC 1260 1310 1360 nm 　
Average Optical Power PAVG -4.5 　 2 dBm 　
Receive Power(OMA) 　 　 　 2.2 dBm 　
Receiver Sensitivity(OMA) SEN 　 　 -8.5 dBm 　

25G Ethernet SFP Optical Module DDM With 1310nm DFB Transmitter


Innovations

The manufacturing environment is strictly compliant with most advanced technological standards, ensuring our products a long term reliability.

Quality & Assurance

Our Cutting-Edge test equipment verifies that each of our products meets our high-quality standards

Customization

Thanks to the specialists of our Engineering Department, we have full control over both the hardware and the software of all our transceivers. Need your personal labelling? No problem, just ask and we provide!

Multi-Compatibility

ColorOptic offers a true cost-effective solution for all major platforms including the original vendor firmware.

Technical Support

Any issues with your equipment? We are already dispatching an engineer to your premises to fix it. We are 7x24 hours online supports.
