Low loss 300 series cable Copper Clad Aluminum with Tinned Copper Braid Low Loss Communications Coaxial cable
Low loss 300 series cable Copper Clad Aluminum with Tinned Copper Braid Low Loss Communications Coaxial cable
Specifications
Brand Name :
Zion communication OR OEM
Model Number :
LLC Coax Cable
Certification :
ISO, CE, RoHS, UL
Place of Origin :
China
MOQ :
1 KM
Payment Terms :
T/T, L/C
Supply Ability :
1000KM / Month
Delivery Time :
25 working days
Packaging Details :
100M, 300M, Wooden Reel, Carton
Inner Conductor :
Copper Clad Aluminum
Dielectric :
Foamed PE
Shield :
Bonded AL Foil
Outer Conductor :
Tinned Copper Braid
Jacket :
PE Black
Description
LLC 300 CCA
NO.7101006
Construction Parameters:
Inner Conductor 1.78mm Copper Clad Aluminum
Dielectric 4.83mm Foamed PE
Shield Bonded AL Foil
Outer Conductor Nom. 5.72mm Tinned Copper Braid
Jacket 7.62mm PE Black
Jacket Thickness
Application
Electrical Characteristics: Low loss 300 series cable Copper Clad Aluminum with Tinned Copper Braid Low Loss Communications Coaxial cable
Capacitance 78.8 pF/m
Impedance 50 Ω
Velocity of Propagation 83%
Insulation Resistantce >5000 M Ω.km
Shielding Effectiveness > 90 dB
Inner Conductor DC Resistance 6.96 Ω/km
Outer Conductor DC Resistance 7.25 Ω/km
VSWR ≤ (Return loss≥dB)
5-3000MHz 1.20 (20)
800-1000MHz 1.10 (26)
1700-2000MHz 1.15 (23)
2000-2400MHz 1.15 (23)
Cross Section:
Low loss 300 series cable Copper Clad Aluminum with Tinned Copper Braid Low Loss Communications Coaxial cable
Mechanical and Environmental Properties:
Cable Bend Radius 38mm
Operating Temperature Range -40 ℃ to +85℃
Cable Diamensions 7.62mm
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100m) Avg.Power(KW)
30 3.50 1.78
50 4.50 1.38
150 7.90 0.79
220 9.60 0.65
450 13.80 0.45
900 19.90 0.31
1500 26.00 0.24
1800 28.70 0.22
2000 30.30 0.21
2500 34.20 0.18
3000 37.50 0.17
5800 54.30 0.11
Order Informations:
Marking HELLOSIGNAL LLC 300 50 Ohm COAXIAL CABLE ×××M
Package Inquired Length on Roll,Wooden Spool,Pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
