High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
High Speed VMC855 CNC Milling Machine 8000 RPM Belt Drive BT40 Taper 24 Tool ATC System for Metal Processing
Specifications
MOQ :
1
table travel (x) (mm) :
1000x550
table travel (z) (mm) :
550mm
no. of spindles :
Single
repeatability (x/y/z) (mm) :
±0.003/300
Price :
$25,000
table travel (y) (mm) :
550mm
weight (t) :
5
min. time of tool change(s) :
8000rpm (ring spray)
max. table load(kg) :
600
Description
VMC855 High-Speed CNC Milling Machine for Metal
The VMC855 Vertical Machining Center is a high-performance CNC milling machine designed for precision metalworking applications. Equipped with the latest Fanuc 0i-MF PLUS control system, this machine delivers exceptional accuracy and reliability for industrial manufacturing.
Key Features
  • X, Y, Z three-axis travel: 800×550×550mm
  • Belt-driven spindle with maximum speed of 8000 RPM (ring spray cooling)
  • 24-position automatic tool changer for efficient operation
  • Heavy-duty box-type head structure with reinforced internal ribs for high rigidity
  • Pneumatic spindle punching mechanism for even stress distribution and extended bearing life
  • Isolated electrical box design with heat exchanger to prevent dust contamination
  • High-precision ball screws with pre-compression nuts and pre-tensioning for minimal backlash
  • Roller linear guides on all axes (6 sliders on Z-axis) for high rigidity and fast positioning
  • Comprehensive laser positioning correction and circular testing for optimal accuracy
Technical Specifications
Parameter Unit Specification
Work table dimension mm 1000×550
X/Y/Z axis travels mm 800/550/550
Distance from spindle end face to table mm 120-670
Distance from spindle center to column mm 590
Maximum load of table Kg 600
Table T-slot mm 5-18×90
X/Y/Z axis fast feed m/min 36/36/36
X/Y/Z rail width mm RGH45/45/45 pin roller
Positional accuracy mm ±0.005
Repeat positioning accuracy mm ±0.003/300
Minimum positioning unit mm ±0.001
Maximum spindle speed rpm 8000 (Ring spray)
Main spindle end taper mm BT40-150
Disk manipulator tool library pcs 24T
Control System / Fanuc 0i-MF PLUS
X/Y/Z axis motor power bis12/bis12/bis22B
Spindle motor power BiL8 (7.5-11KW)
Weight Kg 5000
Dimension mm 2600×2400×2650
Standard Configuration
  • Control system: Fanuc 0i-MF PLUS latest system
  • Maximum spindle speed: 8000rpm (ring spray)
  • Spindle rotation mode: synchronous belt spindle
  • Spindle taper: BT40/150
  • Working range: 800×550×550mm
  • Taiwan 24 disk manipulator tool library
  • Fast moving speed: 48/48/48m/min
  • Complete accessory package including cooling system, lubrication system, cutting and blowing device, working lights, alarm system, and precision adjustment components
  • Advanced features including rigid tapping, accuracy inspection certificate, user manuals, and data transmission interface
  • Premium components including Schneider Electric systems and comprehensive chip management
