Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Z3040 Double Column Vertical Radial Drilling Machine Automatic Take Off And Landing
Specifications
Brand Name :
Matsumoto
Model Number :
Z3040
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
3500USD-4000USD
Payment Terms :
T/T
Delivery Time :
7 WORKING DAYS
Packaging Details :
plywood case
Max. Drilling diameter(mm) :
40
Column diameter(mm) :
230
Spindle speed steps :
6
Weight(kg) :
1200
Overall dimension(mm) :
1800*705*2300
Description

Z3040 High Quality Double Column Vertical Radial Drilling Machine

Description:

  • Mechanical transmission
  • Mechanical clamping
  • Mechanical speed
  • Automatic take-off and landing

Specifications:

Specifications Z3040-13
Max. Drilling diameter(mm) 40
Distance form spindle nose to table surface(mm) 140-1100
Distance from spindle axis to column surface(mm) 330-1200
Column diameter(mm) 230
Spindle travel(mm) 220
Spindle taper(MT) 4
Spindle speeds range(r.p.m) 75,130,240,380,660,1220
Spindle speed steps 6
Spindle feeding range(mm/r) 0.10-0.25
Spindle feeding steps 3
Rocker rotary angle(°) 360°
Main motor power(kw) 2.2
Movements motor power(kw) 1.1
Weight(kg) 1200
Overall dimension(mm) 1800*705*2300

Application:

  • Tool and die making: Performing tapping, reaming, and boring operations on large dies, molds, and jigs that require high positional accuracy.
  • Automotive and locomotive repair: Drilling or reconditioning holes on engine blocks, chassis, and railcar frames during maintenance or customization.

Advantages:

Beyond basic drilling, it can perform reaming, tapping, counterboring, and boring with simple tool changes. This eliminates the need for multiple machines, reducing workshop space requirements and equipment investment.
