400 Ton CNC Hydraulic Press Brake with 8000 mm Working Length and DELEM DA53T Control
400 Ton CNC Hydraulic Press Brake with 8000 mm Working Length and DELEM DA53T Control
400 Ton CNC Hydraulic Press Brake with 8000 mm Working Length and DELEM DA53T Control
400 Ton CNC Hydraulic Press Brake with 8000 mm Working Length and DELEM DA53T Control
400 Ton CNC Hydraulic Press Brake with 8000 mm Working Length and DELEM DA53T Control
400 Ton CNC Hydraulic Press Brake with 8000 mm Working Length and DELEM DA53T Control
Specifications
Brand Name :
CMC
Place of Origin :
Wuxi，Jiangsu, China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Delivery Time :
90days
Working Force :
400 Ton
Working Length :
8000 mm
Motor Power :
30 kW
Stroke :
320 mm
Throat Depth :
950 mm
Control System :
DELEM DA53T
Axis Control :
Y1, Y2
Description
CNC Hydraulic Press Brake Machine
Model: WE67K-400/8000
Electro-Hydraulic CNC Bending Machine with DA53T Control System
Product Overview
WE67K-400/8000 CNC Hydraulic Press Brake is a heavy-duty bending machine designed for large steel plate forming applications. It adopts an electro-hydraulic synchronized CNC system, ensuring stable and precise bending performance for long and thick metal sheets. The machine is widely used in steel structure manufacturing, heavy equipment fabrication, and large metal processing industries.
Technical Specifications
Main Parameters
Item Specification
Machine Type Hydraulic CNC Electro-hydraulic Synchro Press Brake
Working Force 400 Ton
Working Length 8000 mm
Distance Between Frames 5600 mm
Throat Depth 950 mm
Open Height 978 mm
Stroke 320 mm
CNC Control System DELEM DA53T
Controlled Axis Y1, Y2
Working Speed
Item Specification
Unloading Speed 60 mm/s
Working Speed 7 mm/s
Return Speed 60 mm/s
Hydraulic & Electrical System
Item Specification
Hydraulic System Electro-hydraulic synchronized system
Hydraulic Pump High-efficiency industrial pump
Hydraulic Seals Japan / SKF type seals
Hydraulic Components Rexroth type industrial system
Electrical Components Schneider electrical system
Linear Encoder Fagor precision sensor
Power System
Item Specification
Main Motor Power 30 kW High Efficiency Motor
CNC Control System
The machine is equipped with DELEM DA53T CNC system.
Main functions:
  • Y1 / Y2 axis independent control
  • Bending program control
  • Hydraulic synchronization control
  • Parameter adjustment and operation management
The system ensures stable and precise bending performance for industrial applications.
Machine Structure Features
  • Electro-hydraulic synchronized control system
  • Heavy-duty welded frame structure
  • High rigidity machine body design
  • Mechanical crowning system (optional)
  • Designed for large plate bending stability
The structure ensures stable performance under high tonnage and long workpiece conditions.
Application Industry
This CNC press brake is widely used in:
  • Steel structure fabrication
  • Heavy machinery manufacturing
  • Bridge and construction industry
  • Large metal sheet processing
  • Industrial equipment production
Packaging & Installation
  • Machine is disassembled for transport
  • Protective packaging with plastic cover
  • On-site installation and commissioning support available
  • Technical guidance provided by engineers if required
Key Advantages
  • 400 Ton heavy-duty bending capacity
  • 8000 mm extra-long working table
  • Stable electro-hydraulic synchronization system
  • High rigidity frame structure
  • Industrial-grade hydraulic and electrical components
  • Suitable for large steel plate processing
Frequently Asked Questions
Q1: What is the bending capacity of WE67K-400/8000 press brake?
A1: The machine has a bending force of 400 tons with an effective working length of 8000mm, suitable for large steel plate forming.
Q2: What material thickness can this press brake handle?
A2: It is suitable for medium to heavy steel plate bending applications. The exact capacity depends on material strength, bending length, and die configuration.
Q3: What CNC system is used on this machine?
A3: The machine is equipped with DELEM DA53T CNC control system, providing Y1/Y2 axis control and hydraulic synchronization management.
Q4: Is the machine suitable for long workpiece bending?
A4: Yes. The 8000mm working length and tandem-type structure allow stable bending of long steel plates used in structural applications.
Q5: What hydraulic system is used?
A5: The machine adopts an electro-hydraulic synchronized system with industrial-grade hydraulic components for stable pressure control.
