Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Y953 Pneumatic Conveying Material Device
Specifications
Model NO. :
Y953
Control Type :
PLC
Customized :
Customized
Condition :
New
Automatic Grade :
Semi-Automatic
Certification :
CE, RoHS, GS
Type :
Sand Casting
Transport Package :
No
Specification :
500
Trademark :
dingli
Origin :
China
MOQ :
1 Piece
Price :
US $6,000-15,000 /
Description
Y953 Pneumatic Conveying Material DeviceY953 Pneumatic Conveying Material DeviceY953 Pneumatic Conveying Material DeviceY953 Pneumatic Conveying Material DeviceY953 Pneumatic Conveying Material DeviceY953 Pneumatic Conveying Material DeviceThe conveying material delivery device using the kinetic energy of the compressed air, fluidization conveying equipment. Its low power consumption, high productivity, easy operation, can realize multi-point discharging, and a complete set of sealing device and dust removing system; The equipment has high degree of automation and centralized control in the control room.
2. USES:
This device is suitable for conveying coal powder, clay powder, graphite powder, cement, flour, etc., can also be used in pharmaceutical, chemical, metallurgy, food and other industries of all kinds of powder material conveying. Conveying material required temperature does not exceed 50 ºC, water content below 2.5%.
Second, the technical specifications

Mesh according to item number
1 model according to the sender different Y952A effective load volume (m3), 0.2 B
Y953A, 0.3 B
Y954A, 0.4 B
2 work pressure (Mpa) 0.6
3 the compressed air consumption (m3 / t) 13 ~ 15
4 transmission capacity (T/H) 6 ~ 8
5 conveying distance (m) Smax 100 or less
6 conveying height (m) Hmax 15 or less
7 transporting pipe diameter (mm) 30 89 x 4
8 material/gas mixture concentration than the average 50 ~ 60
Up to 75
9 air tank capacity (m3) > 2
Number 10 unloading point this device according to the four discharge point design, can according to user needs to determine unloading point number.
11 control power three-phase ac 380 v voltage 50 hz frequency power supply, control circuit and display circuit for transformer by native to 220 v, 63 v power supply.
12 power (Kw) of 3.6
13 unit weight (T) 6
